Samtec SFM Series Straight Through Hole PCB Socket 40-Contact 2 Row 1.27 mm Pitch 350V 12A Solder Mount SFM-120-01-L-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 12A |
| Model | SFM-120-01-L-D |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | SFM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Contact Gender | Female |
| Connector System | Board-to-Board, Cable |
| Stacking Height | 12mm |
Key Features
- The socket features a solder mount type suitable for durable PCB attachment.
- It supports current rating up to 12 amperes and voltage up to 350 volts.
- Contact material is beryllium copper alloy with gold plating ensuring reliable conductivity and corrosion resistance.
- Operating temperature range is from -55°C to 125°C, suitable for demanding industrial environments.
- The housing is made from liquid crystal polymer providing high mechanical strength and heat resistance.
- Stacking height of 12 mm allows integration in compact PCB assemblies.
- Compatible with multiple header series including TFM, FTS, and FTSH headers for versatile system design.
Product Description
Samtec SFM-120-01-L-D is a high-quality straight through hole PCB socket designed for board-to-board and cable connector applications. This 40-contact, dual-row socket features a standard pitch of 1.27 mm, providing a reliable connection interface in electronic assemblies. Its solder termination and through-hole mounting ensure robust mechanical and electrical performance in industrial and commercial electronic manufacturing.
Constructed from liquid crystal polymer housing, the socket offers excellent mechanical durability and thermal resistance. The contact pins are made from beryllium copper alloy, plated with 0.25 μm gold for enhanced conductivity and longevity. The socket supports a continuous current rating of 12A and withstands voltages up to 350V, making it suitable for a wide range of power and signal transmission applications.
Its operating temperature range from -55°C to 125°C accommodates harsh environmental conditions found in industrial, laboratory, and manufacturing settings. The 12 mm stacking height facilitates compact PCB configurations without sacrificing reliable contact performance.
This series mates with compatible Samtec headers such as the TFM series, FTS series micro terminal strips, and FTSH micro headers, allowing flexible integration options for board-to-board communication and cable connection systems. Designed to meet rigorous quality standards, the SFM-120-01-L-D aids in improving production efficiency and ensuring long-term operational reliability.
The socket is a through-hole type with solder termination for secure PCB mounting. Its dual-row 40-contact configuration suits dense circuit board layouts. Gold-plated beryllium copper contacts ensure excellent electrical performance.
Liquid crystal polymer housing offers mechanical strength and thermal stability. Designed for board-to-board and cable connector applications. Operating temperature range supports demanding industrial environments. Compatible with various Samtec header series for flexible system design.
Ideal for electronics manufacturing, industrial automation, power electronics, and telecommunications applications. Explore the Samtec range for robust PCB connector solutions on EnvMart.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a continuous current rating of 12 amperes.
It can withstand voltages up to 350 volts.
The operating temperature range is from -55°C to 125°C, suitable for demanding industrial environments.
The housing is made from liquid crystal polymer, and the contact pins are made from beryllium copper alloy with gold plating.
This socket features a total of 40 contacts arranged in a dual-row configuration.
The pitch size is 1.27 mm, which is standard for this type of connector.
It utilizes a through-hole mounting type with solder termination for secure PCB attachment.
It is compatible with multiple header series including TFM, FTS, and FTSH headers.
The stacking height is 12 mm, allowing for compact PCB configurations.
It is designed for board-to-board and cable connector applications in electronics manufacturing, industrial automation, and telecommunications.
The country of origin for this product is India.
It supports board-to-board and cable connector systems, providing versatility in electronic assemblies.
