Samtec SSQ Series Right Angle Through Hole PCB Socket 2-Contact 1 Row 2.54 mm Pitch Solder SSQ-102-02-G-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 7.6A |
| Model | SSQ-102-02-G-S-RA |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | SSQ |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- This PCB socket features a right angle orientation suitable for compact board layouts.
- It includes 2 female contacts arranged in a single row with a 2.54 mm pitch.
- The housing is made of durable liquid crystal polymer for high temperature resistance.
- Gold-plated phosphor bronze contacts ensure reliable electrical connectivity and corrosion resistance.
- It supports a maximum current rating of 7.6 A and voltage up to 550 V.
- The socket is mounted through hole for robust mechanical stability.
- Operating temperature range spans from -55°C to +125°C for demanding environments.
- The product is part of the SSQ series, known for board-to-board square post connector solutions.
Product Description
Samtec SSQ-102-02-G-S-RA is a Right Angle Through Hole PCB Socket featuring 2 contacts arranged in a single row with a 2.54 mm pitch. The socket is designed for board-to-board applications requiring dependable electrical and mechanical connection.
The housing is constructed from black liquid crystal polymer providing excellent thermal and mechanical performance. The contacts are made of phosphor bronze material plated with 0.51 μm gold on contact surfaces and gold flash on the tail, ensuring optimized conductivity and corrosion protection.
This through hole mount socket supports a current rating of 7.6 A and voltage rating of 550 V, making it suitable for a variety of electronic assemblies in industrial, commercial, and electronic manufacturing contexts. The operating temperature range from -55°C to 125°C allows use in harsh and varying environmental conditions.
The SSQ series sockets are available in different configurations including single and double rows, with straight or right angle orientations. This specific model is right angle type, facilitating board layout flexibility in compact areas.
Socket strips have square posts and tails designed for secure mating with corresponding Samtec headers such as the TSW (through hole) and TSM (SMT) series. These compatible connectors enable reliable board-to-board interconnection in electronic devices, testing equipment, and industrial instruments.
Right angle orientation suitable for compact board layouts. 2 female contacts in 1 row with 2.54 mm pitch. Liquid crystal polymer housing for thermal resistance. Phosphor bronze contacts plated with gold for conductivity and corrosion resistance.
Rated 7.6 A current and 550 V voltage. Through hole mount type for mechanical stability. Operating temperature from -55°C to +125°C. Compatible with TSW and TSM series headers from Samtec.
This product is ideal for use in electronics manufacturing, prototyping, industrial control systems, communication devices, and laboratory instruments. It supports reliable electrical connections in demanding board-to-board applications.
Explore more PCB Sockets and connectors from Samtec and other leading brands in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a maximum current rating of 7.6 A.
The voltage rating for this model is up to 550 V.
The contacts in this socket are arranged with a pitch of 2.54 mm.
The contacts are made of phosphor bronze and are gold-plated, while the housing is constructed from liquid crystal polymer.
The operating temperature range for this PCB socket spans from -55°C to +125°C.
This model features 2 female contacts arranged in a single row.
This socket uses a through hole mounting type, providing robust mechanical stability.
The SSQ-102-02-G-S-RA has a right angle orientation, suitable for compact board layouts.
This socket is part of the SSQ series, known for board-to-board connector solutions.
It is suitable for use in electronics manufacturing, prototyping, industrial control systems, communication devices, and laboratory instruments.
The termination type for this model is solder.
The country of origin for this PCB socket is India.
