Crydom ED Series Solid State Relay 5A Load 80V dc Load 32V dc Control DIN Rail Mount ED10C5
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 37.4mm |
| Length | 29mm |
| Model | ED10C5 |
| Width | 12.7mm |
| Mount Type | DIN Rail |
| Output type | MOSFET |
| Series | ED |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Capacitance | 10pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Through Hole |
| Switching Function | DC Switching |
| Maximum Load Current | 5A |
| Standards/Approvals | CE, cUL, IEC Rated, RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 740-1312Brand: CrydomManufacturers Part No.: ED10C5Distrelec Article No.: 13744555 |
| Maximum Load Voltage | 80V dc |
| Minimum Load Voltage | 1V dc |
| Minimum Control Voltage | 18V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 20μA |
Key Features
- Supports maximum load current of 5 Amps for robust performance.
- Operates with load voltage up to 80 V dc and control voltage up to 32 V dc.
- Designed for DIN rail mounting with through hole terminals for secure installation.
- Features a SPST contact configuration and MOSFET output type for efficient switching.
- Operates reliably in temperatures ranging from -30°C to 80°C.
- Includes LED input status indicator for operational feedback.
- Complies with CE, cUL, IEC Ratings, and RoHS standards ensuring safety and quality.
- Compact dimensions of 37.4mm height, 29mm length, and 12.7mm width.
Product Description
Crydom ED10C5 ED Series Solid State Relay supports a 5 Amp load current and operates at load voltages up to 80 V dc with control voltage ranging between 18V to 32V dc. It is an industrial-grade DC switching relay designed to fit standard DIN rail mountings with through hole terminals for secure and versatile installation. The relay features a SPST contact configuration and MOSFET output type providing efficient switching capabilities for automation and control applications.
This relay is suitable for a wide range of industrial environments with an operating temperature range from -30°C to 80°C. It includes an LED indicator to provide visual status feedback, enhancing user convenience and operational monitoring. The compact form factor with dimensions 37.4mm (H) x 29mm (L) x 12.7mm (W) makes it appropriate for tight spaces in electrical and automation panels.
Crydom’s ED series solid state relay is cUL recognised, IEC rated, CE and RoHS compliant, ensuring adherence to international quality and safety standards. Its low off state leakage current of 20μA and capacitance of 10pF further boost operational efficiency, making it ideal for use in electrical panels, motor controllers, signal conditioning, and industrial automation systems.
Supports maximum load current of 5 Amps for robust performance. Operates with load voltage up to 80 V dc and control voltage up to 32 V dc. Designed for DIN rail mounting with through hole terminals for secure installation.
Features a SPST contact configuration and MOSFET output type for efficient switching. Operates reliably in temperatures ranging from -30°C to 80°C. Includes LED input status indicator for operational feedback. Complies with CE, cUL, IEC Ratings, and RoHS standards ensuring safety and quality.
Compact dimensions of 37.4mm height, 29mm length, and 12.7mm width. Off state leakage current is low at 20μA supporting energy-efficient operation.
This solid state relay is widely used in industrial automation, electrical panels, motor control systems, and signal conditioning. Its DIN rail mounting capability and industry-standard EMR package make it a versatile choice for various electrical and automation applications.
Explore more Solid State Relays and industrial automation components at EnvMart for quality-assured products meeting your technical requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 5 Amps.
It operates with load voltages up to 80 V dc and a minimum of 1 V dc.
The control voltage for this relay ranges from 18 V dc to 32 V dc.
This solid state relay operates reliably in temperatures ranging from -30°C to 80°C.
It is designed for DIN rail mounting with through hole terminals for secure installation.
The relay features a SPST contact configuration.
It uses a MOSFET output type for efficient switching.
The dimensions are 37.4 mm in height, 29 mm in length, and 12.7 mm in width.
The off state leakage current is low at 20μA, supporting energy-efficient operation.
It complies with CE, cUL, IEC Ratings, and RoHS standards.
This solid state relay is suitable for use in electrical panels, motor controllers, signal conditioning, and industrial automation systems.
The capacitance value is 10 pF.
