onsemi Operational Amplifier, 1.8 MHz Gain Bandwidth, 14-Pin SOIC Surface Mount, 22V MC33174DR2G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.5mm |
| Length | 8.75mm |
| Model | MC33174DR2G |
| Width | 4mm |
| Mount Type | Surface |
| Series | MC33174 |
| Output Current | 5mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 689-6725PBrand: onsemiManufacturers Part No.: MC33174DR2G |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 22V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1.8MHz |
| Input Bias Current | 100 nA |
| Vos - Input Offset Voltage | 4.5 mV |
| Slew Rate | 2.1V/μs |
| Low input offset voltage | 2 mV |
| Input Offset Current | 20 nA |
| Low supply current | 180 μA per Amplifier |
| Wide Bandwidth | 1.8 MHz |
Key Features
- Features a wide bandwidth of 1.8 MHz for high performance amplification.
- Operates on a supply voltage range from 5V to 22V ensuring flexibility.
- Low supply current consumption of 180 microamperes per amplifier for efficiency.
- Includes automotive standard AEC-Q100 qualification enhancing reliability.
- Compact 14-pin SOIC package with dimensions 8.75mm length, 4mm width, and 1.5mm height.
- Offers a high slew rate of 2.1 V/μs for fast signal response.
- Input offset voltage as low as 4.5 mV and bias current of 100 nA for accuracy.
- Maximum output current of 5 mA supporting various signal loads.
Product Description
onsemi MC33174DR2G is a quad operational amplifier designed for surface mount applications requiring low power consumption and wide bandwidth performance. This model offers a gain bandwidth product of 1.8 MHz and operates on supply voltages from 5V up to 22V, making it suitable for a variety of electronic circuit designs in industrial, automotive, and consumer electronics sectors.
The amplifier includes four independent channels within a 14-pin SOIC package, precisely engineered for high slew rates of 2.1 V/μs, enabling rapid response to input signal changes. It features low input offset voltage and low input bias current which enhances signal accuracy, critical for sensitive analog signal processing.
The MC33174DR2G is qualified to automotive AEC-Q100 standards, ensuring reliability under harsh environmental and thermal conditions. Its operational temperature range spans from -40°C to 85°C, suitable for demanding applications in automotive and industrial environments.
Compact dimensions (8.75mm length, 4mm width, 1.5mm height) and surface mount technology facilitate ease of integration on printed circuit boards while maintaining a low power profile with an average supply current of 180 μA per amplifier.
Wide bandwidth of 1.8 MHz for high fidelity signal amplification. Surface mount 14-pin SOIC package for automated PCB assembly. Low supply current enhances energy efficiency in battery-powered systems. Automotive standard AEC-Q100 qualification ensures durability and dependability.
High slew rate of 2.1 V/μs supports fast signal processing. Low input offset voltage and bias current improve measurement precision. Wide operational temperature range for versatile industrial applications. Quad channel configuration offers integration efficiency in multi-signal designs.
Output current capability up to 5 mA supports varied loads.
This operational amplifier is ideal for use in industrial control systems, automotive electronics, consumer audio devices, instrumentation, and communication equipment. Its combination of low power consumption, robust performance, and automotive-grade qualification make it a reliable choice for electronics designers.
Explore more Operational Amplifiers and semiconductor components within EnvMart's Electronics & Electricals category for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the MC33174DR2G is 1.8 MHz, allowing for high performance amplification in various applications.
It operates on a supply voltage range from 5V to 22V, providing flexibility for different circuit designs.
This model features four independent channels, making it suitable for multi-signal designs.
The maximum output current is 5 mA, which supports various signal loads in electronic applications.
The package dimensions are 8.75 mm in length, 4 mm in width, and 1.5 mm in height.
It has a high slew rate of 2.1 V/μs, enabling fast signal response to input changes.
The input offset voltage is as low as 4.5 mV, which enhances measurement accuracy.
The input bias current is 100 nA, contributing to its accuracy in signal processing.
It is qualified to the automotive standard AEC-Q100, ensuring reliability in automotive applications.
The operational temperature range spans from -40°C to 85°C, suitable for demanding environments.
The supply current consumption is 180 μA per amplifier, enhancing energy efficiency in applications.
This model meets RoHS standards, ensuring compliance with environmental regulations.
