STMicroelectronics 200 V 120 A 4-Pin ISOTOP Switching Diode STTH20002TV1
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 4mm |
| Brand | STMicroelectronics |
| Height | 9.1mm |
| Length | 38.2mm |
| Model | STTH20002TV1 |
| Width | 25.5mm |
| Mount Type | Panel |
| Series | STTH20002TV |
| Maximum Operating Temperature | 150°C |
| Package Type | ISOTOP |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Maximum Continuous Forward Current If | 120A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Isolated |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1kA |
| Maximum Forward Voltage Vf | 1.2V |
| Peak Reverse Recovery Time trr | 50ns |
| IXYS 200 V 123 A Diode Switching 12-Pin SOT-227 DSEI2X121-02ABrand | IXYS |
Key Features
- Supports a peak non-repetitive forward surge current of 1kA.
- Features a maximum forward voltage drop of 1.2 V.
- Operates reliably from -55°C to 150°C.
- Isolated diode configuration ensures better insulation.
- Fast peak reverse recovery time of 50 ns aids in switching efficiency.
- Compact size suitable for panel mounting applications.
- Complies with RoHS environmental standards.
- Designed for high current industrial semiconductor usage.
Product Description
STMicroelectronics STTH20002TV1 is a high-performance switching diode designed for applications requiring a peak reverse repetitive voltage of 200 V and a maximum continuous forward current of 120 A. The diode is housed in a 4-pin ISOTOP package, optimized for panel mounting and ensuring efficient heat dissipation and electrical isolation.
This diode supports a peak non-repetitive forward surge current of up to 1 kA, making it ideal for transient current handling in power circuits. Its maximum forward voltage of 1.2 V ensures low conduction losses and higher efficiency in switching applications.
Thermal operation limits range from a minimum of -55°C up to a maximum of 150°C, permitting use in a wide array of industrial environments. Its isolated diode configuration enhances insulation and reduces cross interference, critical in high-power modules.
The STTH20002TV1 achieves a peak reverse recovery time of just 50 nanoseconds, enabling rapid switching and minimizing switching losses, ideal for power supply and inverter circuits.
The compact physical dimensions of length 38.2 mm, width 25.5 mm, height 9.1 mm, and 4 mm diameter allow integration into space-conscious designs. The device is RoHS compliant, supporting environmentally responsible manufacturing.
This diode is suitable for industrial electronics, power rectification, power factor correction, inverter modules, and other semiconductor power device circuits where reliability and high current capacity are critical.
Supports a peak non-repetitive forward surge current of 1kA. Features a maximum forward voltage drop of 1.2 V. Operates reliably from -55°C to 150°C. Isolated diode configuration ensures better insulation. Fast peak reverse recovery time of 50 ns aids in switching efficiency.
Compact size suitable for panel mounting applications. Complies with RoHS environmental standards. Designed for high current industrial semiconductor usage. Explore more high-quality semiconductor components and Diodes from STMicroelectronics on EnvMart for reliable industrial and electronics manufacturing solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 120 A.
The peak reverse repetitive voltage rating is 200 V.
It can handle a peak non-repetitive forward surge current of up to 1 kA.
The dimensions are 38.2 mm in length, 25.5 mm in width, and 9.1 mm in height, with a diameter of 4 mm.
The operating temperature range is from -55°C to 150°C.
The maximum forward voltage drop is 1.2 V.
It features an isolated diode configuration, which enhances insulation.
The peak reverse recovery time is 50 ns, aiding in switching efficiency.
This diode is optimized for panel mounting applications.
It complies with RoHS environmental standards.
It is suitable for industrial electronics, power rectification, power factor correction, and inverter modules.
The STTH20002TV1 has a pin count of 4.
