MaxLinear 2-Channel Line Transceiver TTL Inverting 16-Pin TSSOP SP3232EBEY-L/TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | MaxLinear |
| Height | 1.2mm |
| Length | 5.1mm |
| Model | SP3232EBEY-L/TR |
| Width | 4.5mm |
| Mount Type | Surface |
| Output type | TTL |
| Series | SP3232EB |
| Input Type | Single Ended |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Polarity | Inverting |
| IC Type | Line Transceiver IC |
| Number Of Channels | 2 |
| Pin Count | 16 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS/TTL |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 3V |
| Maximum High Level Output Current | 60mA |
| Maximum Propagation Delay Time @ CL | 150ns |
| Supply Current | 1mA |
Key Features
- Features CMOS/TTL logic family with inverting polarity for signal processing.
- Operates over a wide supply voltage range from 3V to 5.5V.
- Supports two separate channels for versatile line transceiver applications.
- Low supply current of 1mA ensures energy-efficient operation.
- Maximum high level output current of 60mA suitable for robust interfacing.
- Compact dimensions of 5.1 mm length, 4.5 mm width, and 1.2 mm height support dense PCB layouts.
- Wide operating temperature range from -40°C to 85°C ensures performance in harsh environments.
- Surface mount TSSOP package enables automated assembly processes.
Product Description
MaxLinear SP3232EBEY-L/TR is a precision 2-channel line transceiver designed for RS-232 serial communication applications. Featuring a TTL inverting logic interface, this device operates efficiently within a CMOS/TTL logic family, making it ideal for industrial, automotive, and embedded system integration.
It supports a supply voltage range from 3V to 5.5V with a low supply current consumption of just 1mA, enhancing energy savings for battery-operated and power-sensitive applications. The device provides a maximum high level output current of 60mA, allowing robust signal driving capability across the channels.
Housed in a compact 16-pin TSSOP surface mount package with dimensions 5.1 mm (length) by 4.5 mm (width) and 1.2 mm (height), the transceiver fits well in space-constrained designs. It maintains excellent performance over a wide operating temperature range of -40°C to 85°C, suitable for challenging environments including automotive and industrial conditions.
The maximum propagation delay time of 150 ns ensures timely data transfer and signal integrity. This series, SP3232EB, supports drop-in replacement compatibility with popular industry standards, simplifying design and maintenance cycles.
CMOS/TTL logic family with inverting polarity. Two-channel line transceiver with TTL output. 3V to 5.5V supply voltage operation. Low 1mA supply current consumption. Max output current of 60mA per channel. Compact 16-pin TSSOP surface mount package.
Operating temperature range from -40°C to 85°C. 150 ns maximum propagation delay time. Compatible with RS-232 serial communication standards. No certifications or automotive standards applied.
This product is widely applicable in electronics manufacturing, industrial control, automotive systems, and communication hardware requiring reliable line interfacing and signal transceiving.
Explore more semiconductor and interface IC products from MaxLinear on EnvMart for your industrial and commercial needs.
Explore more products in our Line Interface ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates over a supply voltage range from 3V to 5.5V.
It supports two separate channels for versatile line transceiver applications.
The maximum high level output current is 60mA per channel, suitable for robust interfacing.
The dimensions are 5.1 mm in length, 4.5 mm in width, and 1.2 mm in height.
The maximum propagation delay time is 150 ns, ensuring timely data transfer.
It features a CMOS/TTL logic family with inverting polarity for signal processing.
The supply current consumption is low, at just 1mA, enhancing energy efficiency.
The operating temperature range is from -40°C to 85°C, making it suitable for harsh environments.
It comes in a compact 16-pin TSSOP surface mount package, suitable for dense PCB layouts.
Yes, it is compatible with RS-232 serial communication standards.
It is widely applicable in electronics manufacturing, industrial control, automotive systems, and communication hardware.
The input type is single-ended, which is typical for line transceiver applications.
