TE Connectivity Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header, 4 Contacts, 4.14 mm Pitch 1-770968-1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 9.5A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Universal MATE-N-LOK |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -20°C |
| Number of Rows | 2 |
| Pitch | 4.14mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- This PCB header supports a current rating of 9.5A and voltage rating of 600V.
- Features a shrouded, right-angle orientation with two rows of contacts for secure connections.
- Constructed with a UL94V-0 nylon housing for excellent durability and safety.
- Brass contacts plated with gold ensure reliable conductivity and corrosion resistance.
- Termination is by solder, suitable for through-hole mount PCB installations.
- Operating temperature ranges from -20°C to 85°C, suitable for varied industrial environments.
- Incorporates a positive locking latch mechanism and board locks to secure the connector on the PCB.
Product Description
TE Connectivity 1-770968-1 Mini-Universal MATE-N-LOK Series Right Angle Through Hole PCB Header is a high-quality connector designed for reliable wire-to-board connectivity in electronic assemblies. It features 4 gold-plated brass contacts spaced at a 4.14 mm pitch arranged in two rows with a right-angle orientation to facilitate optimal PCB integration.
The housing is made of UL94V-0 rated nylon material which provides excellent flame retardance and mechanical strength. This connector system supports a current capacity of 9.5 amperes and a voltage rating up to 600 volts, making it suitable for a wide range of electrical and electronic applications.
Designed for through-hole mounting, this header ensures robust solder termination to maintain strong mechanical and electrical connections on the PCB. The connector includes a positive locking latch and board locks to prevent disconnection or movement during operation, enhancing reliability in industrial, manufacturing, and laboratory environments.
Operating temperature range from -20 degrees Celsius to 85 degrees Celsius allows use in diverse climate conditions, typical in industrial and commercial sectors.
This connector system is part of the Mini-Universal MATE-N-LOK Series from TE Connectivity, known for manufacturing durable and precision connectors suitable for complex electrical assemblies and wire harnesses.
This product provides a current rating of 9.5A and voltage rating of 600V. Features a right-angle, shrouded housing made of flame-retardant nylon. Equipped with gold-plated brass contacts for superior conductivity and durability.
Includes a positive locking latch and board locks for secure PCB retention. Supports through-hole mounting with solder termination for stable connections. Operates reliably over temperatures from -20°C to 85°C. Designed for wire-to-board applications in industrial and commercial setups.
Explore the TE Connectivity Mini-Universal MATE-N-LOK connector range at EnvMart for industrial, laboratory, and manufacturing solutions requiring dependable PCB interconnections.
Explore more products in our PCB Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 9.5A and a voltage rating of 600V.
It is designed for through-hole mounting with solder termination, ensuring stable connections on the PCB.
The housing is made of UL94V-0 rated nylon, while the contacts are brass plated with gold for reliable conductivity and corrosion resistance.
The contacts are spaced at a 4.14 mm pitch and arranged in a right-angle orientation with two rows.
It operates reliably within a temperature range of -20°C to 85°C, suitable for various industrial environments.
Yes, it incorporates a positive locking latch mechanism and board locks to secure the connector on the PCB.
This PCB header features 4 contacts.
It is a wire-to-board connector system, designed for reliable interconnections in electronic assemblies.
The contacts are male gender.
The country of origin for this model is India.
This connector is part of the Mini-Universal MATE-N-LOK Series from TE Connectivity.
This model features a shrouded design, which enhances connection security and reliability.
