Texas Instruments Operational Amplifier 3 MHz, 8-Pin SOIC, 3V to 5.5V Supply OPA2337UA
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | OPA2337UA |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | OPA2336 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 3MHz |
| Input Bias Current | ±10 pA |
| Vos - Input Offset Voltage | ±3 mV |
| Slew Rate | 1.2V/μs |
Key Features
- Features a Gain Bandwidth Product of 3 MHz for reliable signal amplification.
- Operates on a minimum supply voltage of 3 V and maximum of 5.5 V.
- Equipped with 8-pin SOIC surface mount package for easy PCB integration.
- Includes 2 channels allowing dual operational amplifier configurations.
- Input offset voltage is ±3 mV ensuring precision in low voltage applications.
- Very low input bias current of ±10 pA for minimal signal load.
- Operates effectively between temperatures of -40°C to 85°C for industrial and automotive applications.
- Slew rate of 1.2 V/μs supports medium-speed transient response.
Product Description
Texas Instruments model OPA2337UA is a dual-channel operational amplifier offering a 3 MHz gain bandwidth product designed for precision amplification within low voltage applications. The device supports a voltage supply range from 3 V up to 5.5 V, making it suitable for varied embedded and industrial electronics environments.
This operational amplifier is housed in an 8-pin SOIC surface mount package, providing a compact footprint ideal for PCB integration in space-constrained systems. Its low input offset voltage of ±3 mV and exceptionally low input bias current of ±10 pA ensure high accuracy signal processing, crucial for sensitive analog circuits.
OPA2337UA operates reliably in a wide temperature range from -40°C to 85°C, supporting use in harsh conditions including automotive and industrial applications. The device features a slew rate of 1.2 V/μs which enables it to handle moderate speed signal changes effectively.
Physical dimensions of the amplifier are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height, making it suitable for compact electronic designs. The OPA2337UA belongs to the OPA2336 series known for low noise and precision performance in semiconductor amplifiers.
Gain bandwidth product: 3 MHz. Power supply range: 3 V to 5.5 V. Surface mount SOIC package with 8 pins. Dual-channel operational amplifier. Input offset voltage: ±3 mV. Input bias current: ±10 pA. Operating temperature: -40°C to 85°C.
Slew rate: 1.2 V/μs. Compact dimensions: 4.9 mm (L) x 3.91 mm (W) x 1.58 mm (H).
This operational amplifier is widely applicable in industrial, laboratory, automotive, and manufacturing electronic control systems, providing efficient and accurate signal amplification solutions. It supports engineers designing precision analog circuits where low power and high stability are essential.
Explore additional Texas Instruments semiconductor products and Operational Amplifiers on EnvMart for a comprehensive selection tailored to diverse industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 3 MHz, enabling reliable signal amplification.
It operates on a supply voltage range from 3 V to 5.5 V, making it suitable for various applications.
This operational amplifier features 2 channels, allowing for dual operational amplifier configurations.
The input offset voltage is ±3 mV, ensuring precision in low voltage applications.
It has a very low input bias current of ±10 pA, which minimizes signal loading.
The OPA2337UA operates effectively between -40°C and 85°C, suitable for industrial and automotive applications.
The slew rate is 1.2 V/μs, supporting medium-speed transient response.
It measures 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height, making it compact for PCB integration.
This model is housed in an 8-pin SOIC surface mount package, ideal for space-constrained designs.
It belongs to the OPA2336 series, known for low noise and precision performance in semiconductor amplifiers.
It is widely applicable in industrial, laboratory, automotive, and manufacturing electronic control systems.
The country of origin for this operational amplifier is India.
