onsemi 36 V 5 W Voltage Regulator Zener Diode Single 2-Pin DO-15 1N5365BRLG

The onsemi 1N5365BRLG Zener Diode is a single-element voltage regulator diode designed for industrial and electronic applications requiring stable voltage reference and regulation. It operates at a nominal Zener voltage of 36 volts with a tolerance of ±5%, ensuring precise voltage control in circuits.

The device supports through hole mounting type and is housed in a durable DO-15 package with two pins, allowing easy integration into printed circuit boards designed for power regulation. It can dissipate power up to 5 watts, suitable for moderate power applications.

With a test current of 30 mA and maximum Zener impedance of 160 ohms, this diode maintains consistent performance under standard test conditions. Its maximum reverse leakage current is only 500 nA, minimizing losses and improving circuit efficiency.

The operational temperature span of -65°C to +200°C makes the 1N5365BRLG reliable in a range of industrial environments including harsh temperature fluctuations. The compact physical dimensions, 8.89 mm length and 3.68 mm height, allow for compact circuit designs.

Through hole mount for easy PCB integration. 5 watts maximum power dissipation for moderate power circuits. Voltage regulation with ±5% tolerance at 36 V nominal voltage. Low maximum reverse leakage current of 500 nanoamperes.

Wide operating temperature range from -65°C to +200°C. Compact 2-pin DO-15 package design.

This zener diode is ideal for electronic projects, industrial power supplies, and voltage regulation circuits requiring reliable and accurate voltage clamping functionality. It supports a diverse range of industrial and commercial applications in power electronics, semiconductor devices, and discrete component designs.
