| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 1.15mm |
| Length | 3.1mm |
| Model | BZX84C3V3LYFHT116 |
| Mount Type | Surface |
| Series | BZX84C |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 250mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 3.3V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 95Ω |
| Typical Voltage Temperature Coefficient | 0mV/°C |
ROHM BZX84C3V3LYFHT116 is a high-reliability Zener Diode designed for voltage regulation applications. It features a nominal Zener voltage of 3.3 V and a maximum power dissipation of 250 mW, housed in the common surface mount SOT-23 3-pin package. This diode offers excellent electrical performance with a test current of 5 mA and maximum reverse leakage current limited to 5 μA, ensuring efficient power regulation in compact electronics.
With a maximum operating temperature of 150°C and compliance with RoHS and AEC-Q101 automotive standards, this component is suitable for demanding industrial, automotive, and commercial electronic applications. The diode has a compact physical size of 3.1 mm length and 1.15 mm height, making it ideal for space-constrained PCB layouts.
The maximum Zener impedance of 95 Ω and zero typical voltage temperature coefficient contribute to a stable voltage reference, minimizing fluctuation across a wide temperature range. Its single diode configuration with three pins supports straightforward integration into voltage regulator circuits and protection modules.
This ROHM Zener Diode is widely used in construction of power supplies, voltage clipping circuits, and precision voltage reference setups in electronic manufacturing, automotive electronics, instrumentation, and industrial control systems.
Single diode configuration for precise voltage regulation. Surface mount SOT-23 package suitable for automated PCB assembly. Maximum operating temperature of 150°C for enhanced durability. Low leakage current and impedance ensuring efficient operation.
Compliance with environmental RoHS regulations and automotive quality standards (AEC-Q101). Compact dimensions facilitating high-density electronic assemblies. Stable voltage performance with test current of 5 mA and zero voltage temperature coefficient.
Ideal for industrial, automotive, laboratory, and manufacturing electronics. Explore the full range of ROHM semiconductor components and related electronic parts at EnvMart's dedicated Electronics & Electricals category.
