| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 0.6mm |
| Length | 2.5mm |
| Model | PLZ16B-HG3_A/H |
| Mount Type | Surface |
| Series | PLZ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-219AC (MicroSMF) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 10mA |
| Maximum Reverse Leakage Current | 200nA |
| Nominal Zener Voltage Vz | 16.04V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 18Ω |
Vishay PLZ16B-HG3_A/H is a general purpose silicon planar Zener diode designed for surface mount applications, featuring a low profile DO-219AC (MicroSMF) package. It offers a nominal Zener voltage rating of 16.04 V combined with a maximum power dissipation of 500 mW, suitable for voltage regulation tasks in compact electronic circuits.
This diode maintains excellent electrical stability and low leakage current, making it reliable for industrial, automotive, and commercial electronics usage. The diode works efficiently over a broad temperature range from -55°C to 150°C, ensuring robustness under harsh conditions.
The device’s pin count of two and single element chip design simplifies mounting and circuit integration. Its construction conforms to RoHS directives and IEC standards 61000-4-2 and 61760-1. It is also compliant with automotive standard AEC-Q101, certifying high quality and durability for vehicle electronics.
Its surface mount configuration allows for wave and reflow soldering processes with terminal soldering temperatures reaching 260°C, aiding modern automated assembly. The diode is ideal for use in power supply protection, voltage stabilization, and discrete semiconductor circuits encountered in industrial and electronic component manufacturing.
Surface mount diode in compact DO-219AC (MicroSMF) package. Nominal Zener voltage of 16.04 volts providing regulated voltage capabilities. Maximum power dissipation of 500 milliwatts ensuring reliable performance. Low leakage current of 200 nanoamperes and maximum Zener impedance of 18 ohms.
Wide operating temperature range from -55°C to 150°C suitable for various environments. Single element chip with 2-pin configuration optimized for general purpose applications. Compliant with RoHS standards and automotive grade AEC-Q101 certified.
Wave and reflow solderable with high temperature soldering up to 260°C. Explore Vishay and related semiconductor components at EnvMart for quality assurance and comprehensive industrial application support.
