| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1mm |
| Length | 2.2mm |
| Model | BAT54AW,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | BAT54 |
| Maximum Operating Temperature | 125°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Common Anode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 2μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 800mV |
| Peak Reverse Recovery Time trr | 5ns |
Nexperia BAT54AW,115 Schottky Diode is a high-performance discrete semiconductor designed for efficient power rectification and switching. This surface mount diode features a 3-Pin SC-70 package with ultra-small dimensions, making it suitable for compact PCB designs.
With a maximum continuous forward current rating of 200 mA and a peak reverse repetitive voltage of 30 V, it delivers reliable performance under challenging electrical conditions. The diode's forward voltage drop is optimized at 800 mV, enabling energy-efficient operation while minimizing heat dissipation.
The diode supports a wide operating temperature range from -65°C to 125°C and conforms to the stringent AEC-Q101 automotive quality standard, highlighting its suitability for automotive and industrial applications requiring high reliability.
Its fast peak reverse recovery time of 5 ns and low leakage characteristics ensure minimal power loss and rapid switching capabilities, crucial for high-frequency electronic circuits. The common anode configuration and Schottky barrier technology further enhance its switching efficiency and reduce power consumption.
This component finds extensive use in power management circuits, voltage clamping, reverse polarity protection, and general-purpose rectification in automotive electronics, telecommunications equipment, consumer electronics, and other commercial and industrial electronic systems.
Maximum continuous forward current: 200 mA. Peak reverse repetitive voltage: 30 V. 3-Pin SC-70 surface mount package. Forward voltage drop: 800 mV. Operating temperature range: -65°C to 125°C. Peak reverse recovery time: 5 ns.
Low leakage current: 2 μA peak reverse current. Automotive standard: AEC-Q101 certified. Common anode diode configuration.
The Nexperia BAT54AW,115 diode is an essential component for industries focusing on high-efficiency, compact, and reliable semiconductor solutions. Browse more Schottky Diodes and rectifiers at EnvMart to find components tailored to your project requirements.
