Texas Instruments Current Shunt Monitor Single 5-Pin SOT-23 INA196AIDBVT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.15mm |
| Length | 2.9mm |
| Model | INA196AIDBVT |
| Mount Type | Surface |
| Series | INA196 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 5 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 900μA |
| GBP - Gain Bandwidth Product | 500kHz |
| CMRR - Common Mode Rejection Ratio | 80dB |
Key Features
- The device operates with a supply voltage range from 2.7V to 18V.
- It features a common mode rejection ratio (CMRR) of 80dB, enhancing measurement accuracy.
- Supply current is low at 900μA ideal for efficient power management.
- Packaged in a compact 5-pin SOT-23 surface mount package measuring 2.9mm by 1.15mm.
- Designed for operation in temperatures from -40°C to 125°C, suitable for harsh environments.
- Gain bandwidth product (GBP) of 500kHz supports responsive current measurement.
- Single channel current sensing amplifier for real-time system monitoring and protection.
- Ideal for industrial, automotive, and electronics applications requiring precise current measurement.
Product Description
Texas Instruments INA196AIDBVT is a single supply current shunt monitor designed for precise current sensing applications. This device offers a voltage output proportional to the voltage drop across a low-value resistor placed in the high-current power rail, enabling accurate current measurement essential for system protection, feedback control, and monitoring.
The INA196AIDBVT supports a supply voltage range from 2.7V to 18V and operates efficiently with a low supply current of 900μA. With an 80dB common mode rejection ratio, this device minimizes interference from voltage common mode signals, ensuring high measurement fidelity across a wide dynamic range.
Housed in a compact surface mount 5-pin SOT-23 package with dimensions of 2.9 mm length and 1.15 mm height, the device is well-suited for space-constrained designs. It is rated for operation in extreme environments, functioning reliably from -40°C up to 125°C, making it applicable in automotive and industrial contexts.
The device features a gain bandwidth product of 500kHz, which allows it to respond rapidly to changes in current flow, suitable for real-time monitoring systems. Its single channel design simplifies integration into various electrical and electronic control systems.
Texas Instruments INA196AIDBVT current sensing amplifiers are widely used in industrial machines, laboratory instrumentation, HVAC systems, and power management modules where accurate current measurement and control are critical.
The device operates at a minimum supply voltage of 2.7V and maximum of 18V. It has a common mode rejection ratio of 80dB for stable output. Low supply current of 900μA reduces power consumption. Surface mount 5-pin SOT-23 package for compact installation.
Wide operating temperature range from -40°C to 125°C. Gain bandwidth product is 500kHz for quick response. Single channel configuration for simplified use. Suitable for automotive and industrial applications. Explore more semiconductor Current Sensing Amplifiers at EnvMart to find suitable solutions for your industrial and laboratory measurement needs.
