Abracon 20 MHz Crystal Unit ±30 ppm Frequency Tolerance HC-49-US Package 2-Pin Through Hole ABLS-20.000MHZ-K4T

Abracon ABLS-20.000MHZ-K4T is a 20 MHz crystal unit designed for reliable frequency generation with a ±30 ppm tolerance, housed in the HC-49-US through-hole package. It features a load capacitance of 16 pF and is supplied on tape and reel to facilitate high volume manufacturing and automated pick-and-place assembly.

This crystal has a pin configuration of 2 pins and compact dimensions of 11.5 mm length, 4.7 mm width, and 4.2 mm height, which makes it suitable for various electronic circuit boards. It excels in frequency stability with ±50 ppm, ensuring precise oscillation critical for timing circuits and frequency control in electronic systems.

The unit performs reliably within a temperature range of 0°C to 70°C, making it appropriate for standard industrial and commercial environmental conditions. Its maximum series resistance of 40 Ω supports efficient signal quality. Being RoHS compliant and lead-free, it is suitable for environmentally conscious manufacturing processes.

This crystal unit is ideal for a wide range of applications including computers, modems, microprocessors, and wireless communications equipment, where stable and accurate frequency control is essential for device performance and reliability.

This crystal unit operates at a standard frequency of 20 MHz. Features a load capacitance of 16 pF to ensure stable oscillations. Packaged in tape and reel format for automated assembly processes. Designed with 2 pins and a compact HC-49-US package.

Dimensions measure 11.5 mm in length, 4.7 mm in width, and 4.2 mm in height. Operates within a temperature range of 0°C to 70°C. Frequency stability is ±50 ppm, supporting consistent performance. Series resistance is rated at a maximum of 40 Ω.

RoHS compliant and lead-free, suitable for modern electronics manufacturing. Applicable for use in computers, modems, microprocessors, and wireless devices. Explore more Crystal Units and electronic components at EnvMart for your industrial and commercial needs.
