Texas Instruments Operational Amplifier 700 kHz 8-Pin 26V SOIC LM2904D
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | LM2904D |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LM2904 |
| Output Current | -10mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 26V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 700kHz |
| Input Bias Current | -500 nA |
| Vos - Input Offset Voltage | 10 mV |
| Slew Rate | 0.3V/μs |
| Input Offset Current | 300 nA |
| LM2904D Texas Instruments, Operational Amplifier, 700 kHz, 8-Pin 26V SOICBrand | Texas Instruments |
| LM2904D Texas Instruments, Op Amp, 700kHz, 5 → 24 V, 8-Pin SOICBrand | Texas Instruments |
Key Features
- Offers dual channels in a single package for versatile uses.
- Supports a wide supply voltage range from 5V to 26V.
- Operates reliably between -40°C and 125°C temperatures.
- Features a slew rate of 0.3V/µs for stable signal amplification.
- Input offset voltage is maintained at a low 10 mV for accuracy.
- Compact SOIC package with dimensions 4.9 mm length, 3.91 mm width, and 1.58 mm height.
- Meets RoHS compliance and environmental standards.
- Suitable for industrial, laboratory, electronics, and semiconductor applications.
Product Description
Texas Instruments LM2904D Operational Amplifier is a high-performance, general-purpose device with a gain bandwidth of 700 kHz, supplied in an 8-pin SOIC surface mount package. This dual-channel operational amplifier supports supply voltages ranging from 5V up to 26V, making it adaptable for varied electronic circuit requirements.
With a slew rate of 0.3 V/µs and an input offset voltage of 10 mV, the LM2904D ensures reliable signal amplification with low distortion. It functions efficiently in harsh environments within the temperature range of -40°C to 125°C, suitable for a wide range of industrial and electronic applications.
The compact SOIC package, measuring 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height, aids in space-efficient PCB layouts. The device complies with RoHS standards, reflecting its adherence to environmental regulations.
This operational amplifier finds extensive applications in industrial instrumentation, laboratory equipment, electronic components, and semiconductor devices. Its low power consumption and stable operation make it excellent for both consumer and professional-grade electronic assemblies.
Dual operational amplifier channels support complex circuit designs efficiently. Wide voltage supply range providing flexibility across various applications. High speed and low offset voltage enhance signal integrity. Compact SOIC form factor enables easy integration in modern electronics.
RoHS compliant and environmentally friendly design. Engineered for automotive and industrial temperature ranges. Manufactured in Malaysia, assuring quality and performance standards. Explore the full product range for Operational Amplifiers and related semiconductor components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 700 kHz.
It supports a supply voltage range from 5V to 26V.
The dimensions of the SOIC package are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
It operates reliably between -40°C and 125°C.
The input offset voltage is maintained at a low 10 mV for accuracy.
This model features dual channels in a single package.
The slew rate is 0.3 V/µs, which helps in stable signal amplification.
The maximum output current is -10 mA.
Yes, it meets RoHS compliance and environmental standards.
The input bias current is -500 nA.
It uses a surface mount configuration.
It is manufactured in Malaysia, ensuring quality and performance standards.
