Fluke Handheld Digital Multimeter True RMS 10 A 1 kV Fluke 177

Free Delivery in India | Lowest Global Shipping Charges

Fluke Handheld Digital Multimeter True RMS 10 A 1 kV Fluke 177

Name: Fluke Handheld Digital Multimeter True RMS 10 A 1 kV Fluke 177
Brand: FLUKE
SKU: 182832
Price: 683.06 USD
Availability: InStock



Category Digital Multimeter Brand FLUKE Condition New

Specifications

Country of Origin	United States
Display Type	LCD
Brand	Fluke
Battery Life	200h
Battery type	Alkaline
Height	43mm
Length	185mm
Model	Fluke 177
Gross Weight	420g
Width	90mm
Maximum Operating Temperature	50°C
AC Voltage Resolution	0.1mV ac
Minimum Operating Temperature	-10°C
DC Current Accuracy	±1 % rdg + 3 Digits
DC Voltage Resolution	0.1 mV dc
Resistance Measurement Accuracy	0.9% + 1
AC Current Accuracy	±1.5 % rdg + 3 Digits
Resistance Resolution	100mΩ
AC Current Resolution	10μA ac
DC Current Resolution	0.01mA dc
Multimeter Type	Handheld
Functions Measured	AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance
Maximum Resistance Measurement	0.05GΩ
Maximum AC Current Measurement	10A
Maximum DC Voltage Measurement	1kV dc
Maximum AC Voltage Measurement	1kV
Maximum Frequency	100kHz
Safety Category Level	CAT III, CAT IV
Safety Category Voltage	1kV
Chauvin Arnoux Handheld Multimeter, 10 A ac, 10 A dc, 1 kV acBrand	Chauvin Arnoux
Fluke 175 Handheld Digital Multimeter True RMS, 10 A, 10 A, 1 kVBrand	Fluke
177 LCD Digital Multimeter, True RMS, 10A ac Max, 10A dc Max, 1000V ac MaxBrand	Fluke

Key Features

True RMS measurement for precise AC readings on complex waveforms.
Capable of measuring up to 10 A current, suitable for load and supply checks.
High voltage capability with 1 kV DC and AC measurement range.
Measures AC/DC voltage, current, resistance, capacitance, frequency, continuity, and diode functions.
Resolutions of 0.1 mV for DC voltage and 0.01 mA for DC current enable fine measurements.
Wide frequency range up to 100 kHz for fast signal detection.
Robust safety rating with CAT III and CAT IV compliance up to 1000 V system voltages.
Operates on alkaline battery with approximately 200 hours battery life.

Product Description

Fluke Fluke 177 handheld digital multimeter True RMS is a precision measuring instrument engineered for industrial, laboratory, and field use. With a robust design and wide measurement capabilities, it ensures accurate and reliable diagnostics for electrical systems.

This instrument delivers true RMS measurements for accurate AC readings, critical for complex waveform analysis. It measures AC and DC voltages up to 1 kV and currents up to 10 A, supporting thorough testing of electrical loads and supplies.

Equipped with high resolution and accuracy, the Fluke 177 can detect as low as 0.1 mV in DC voltage and 0.01 mA in DC current, making it suitable for sensitive electronic measurements. It supports resistance up to 0.05 GΩ, capacitance, frequency, continuity, and diode testing, making it versatile for a wide range of electrical troubleshooting tasks.

The meter meets stringent safety category standards CAT III and CAT IV at 1000 V, ensuring safe use in demanding industrial environments. The device operates efficiently within a temperature range of -10°C to 50°C, and battery life is around 200 hours with alkaline batteries, reducing downtime.

Its compact dimensions of 185 mm length, 90 mm width, and 43 mm height, combined with a lightweight 420 g gross weight, make it convenient for fieldwork and workshops. True RMS measurement delivers accurate AC readings for complex waveforms.

Supports measurement of voltage, current, resistance, capacitance, frequency, continuity, and diode test functions. High safety ratings CAT III and CAT IV up to 1000 V for secure electrical testing. Wide operating temperature range suitable for various industrial conditions.

Long battery life of approximately 200 hours ensures extended use. Compact and lightweight handheld design for ease of portability. Capable of measuring high voltage up to 1 kV and current up to 10 A. High measurement resolution for detailed diagnostics.

Widely used in industrial, laboratory, HVAC, electrical maintenance, and manufacturing sectors. Environmentally robust for field and workshop measurements. Explore EnvMart's extensive range of Digital Multimeters and measuring instruments for precise and reliable electrical diagnostics across industries.
