Texas Instruments Operational Amplifier 3 MHz Gain Bandwidth 14-Pin SOIC TL074ACD
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 8.65mm |
| Model | TL074ACD |
| Width | 3.91mm |
| Mount Type | Surface |
| Low Noise | 18nV/√Hz typical at 1 kHz |
| Series | TL074 |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 3MHz |
| Input Bias Current | 7 nA |
| Vos - Input Offset Voltage | 7.5 mV |
| Slew Rate | 13V/μs |
| Input Offset Current | 2 nA |
| Wide supply voltage range | ±5 to ±15V |
| High Slew Rate | 13 V/μs typical |
| Low Total Harmonic Distortion | 0.003% typical |
Key Features
- Features a JFET input stage offering low input bias and offset currents.
- Wide supply voltage range from ±5V to ±15V for versatile operation.
- Low noise level of 18nV/√Hz typical at 1 kHz ensures high signal integrity.
- High slew rate of 13 V/μs typical allows fast waveform response.
- Low total harmonic distortion at 0.003% typical for clean amplification.
- Surface mount package Type SOIC with 14 pins for compact circuit design.
- Operating temperature range from 0°C to 70°C suitable for standard industrial environments.
- Quad channel operational amplifier ideal for multiple signal processing tasks.
Product Description
Texas Instruments TL074ACD is a precision JFET input operational amplifier featuring four independent amplifiers in a 14-pin SOIC package. With a gain bandwidth product of 3 MHz and a high slew rate of 13 V/μs, this device is suitable for a wide range of audio and signal processing applications requiring high speed and low noise performance.
The device operates over a wide supply range from ±5V to ±15V making it adaptable for various power supply configurations. Low input bias and offset currents enhance measurement accuracy especially in sensor interfacing and precision analog circuits. Its low total harmonic distortion of 0.003% ensures minimal signal degradation during amplification.
Physical dimensions (Length: 8.65 mm, Width: 3.91 mm, Height: 1.58 mm) and surface mount SOIC package type allow compact integration into printed circuit boards with limited space. The operational temperature range of 0°C to 70°C makes it suitable for typical industrial applications.
This operational amplifier is widely used in industrial, laboratory, audio processing, instrumentation, and control systems. It supports applications such as analog signal conditioning, active filtering, sensor amplifiers, and audio preamplifiers.
High performance quad operational amplifier with JFET inputs. Low noise and distortion for audio and signal fidelity. Wide supply voltage and temperature range for versatile usage. Compact SOIC 14-pin package. Slew rate and bandwidth optimized for fast response circuits.
Suitable for industrial, laboratory and audio electronics applications. Explore additional Texas Instruments Operational Amplifiers and other semiconductor products at EnvMart for your electronics and electrical design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TL074ACD has a gain bandwidth product of 3 MHz, making it suitable for high-speed applications.
This model operates within a temperature range of 0°C to 70°C, suitable for standard industrial applications.
The TL074ACD features four independent channels, allowing for multiple signal processing tasks.
It has a typical noise level of 18nV/√Hz at 1 kHz, ensuring high signal integrity.
The TL074ACD has a typical slew rate of 13 V/μs, enabling fast waveform response.
The input bias current for this model is 7 nA, which enhances measurement accuracy.
This operational amplifier has dimensions of 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height.
The TL074ACD comes in a surface mount SOIC package with 14 pins, allowing for compact circuit design.
The total harmonic distortion is typically 0.003%, which ensures minimal signal degradation during amplification.
It supports a wide supply voltage range from ±5V to ±15V, making it adaptable for various power supply configurations.
This operational amplifier is suitable for applications such as analog signal conditioning, active filtering, and audio preamplifiers.
The input offset voltage for this model is 7.5 mV, contributing to its precision in measurements.
