Omron PCB Power Relay 12V DC Coil 15A Switching Current SPST G5CA-1A-E DC12
Specifications
| Country of Origin | India |
|---|---|
| Brand | Omron |
| Height | 11mm |
| Length | 22mm |
| Model | G5CA-1A-E DC12 |
| Width | 16mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | G5CA |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -25°C |
| Switching Current | 15A |
| Terminal type | Solder |
| Standards/Approvals | CE, EN, IEC, RoHS, UL |
| Coil Resistance | 720Ω |
| Coil Voltage | 12V dc |
| Switching AC Voltage | 400V ac |
| Coil Power | 200mW |
| SPST-NO min PCB relay,15A 12Vdc coilBrand | Omron |
Key Features
- This relay operates with a coil resistance of 720 ohms providing coil power of 200mW.
- It features a compact design measuring 22mm in length, 16mm in width, and 11mm in height.
- The contact configuration is SPST with silver alloy contact material for enhanced conductivity.
- It supports switching AC voltage up to 400V AC and operates in temperature ranges from -25°C to 70°C.
- The relay is suitable for PCB mounting using solder terminal types.
- Approved by CE, EN, IEC, RoHS, and UL standards ensuring quality and compliance.
- The product is ideal for switching power in household appliances and industrial device outputs.
Product Description
Omron G5CA-1A-E DC12 PCB Power Relay is a sub-miniature, flux proof power relay with a coil voltage of 12V DC and a switching current capacity of 15A. It features a SPST contact configuration and is designed specifically for PCB mounting with solder terminals. The relay's compact dimensions of 22mm length, 16mm width, and 11mm height make it suitable for tight spaces.
This relay operates with high reliability over a temperature range from -25°C to 70°C. The contact material using silver alloy ensures excellent electrical performance and durability. Its coil resistance of 720Ω and coil power rating of 200mW highlight the efficient coil design, minimizing power consumption.
The G5CA series relay conforms to international standards including CE, EN, IEC, RoHS, and UL certifications, making it a proven component in industrial and household applications. It is ideal for switching power in household appliances or for outputs from industrial control devices, offering a dependable solution where a compact and robust relay is required.
This relay operates efficiently at 12V DC coil voltage with 15A switching current. Compact size of 22x16x11 mm fits well in dense PCB layouts. Silver alloy contact material provides low resistance and longevity. Suitable for applications ranging from industrial controls to household appliances.
Compliant with global safety and quality standards such as CE and UL. Flux proof design enhances durability and reliability in various environments. Operates effectively in temperatures from -25°C to 70°C.
For reliable and efficient power switching on PCBs, the Omron G5CA-1A-E DC12 relay offers a compact, certified, and high-quality solution. Browse more Power Relays and related components on EnvMart to find the perfect match for your electrical and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is 12V DC.
It has a maximum switching current capacity of 15A.
This relay measures 22mm in length, 16mm in width, and 11mm in height.
The contact configuration is SPST (Single Pole Single Throw).
The coil resistance is 720 ohms.
It is designed for PCB mounting using solder terminals.
The relay operates effectively within a temperature range of -25°C to 70°C.
It can switch AC voltage up to 400V AC.
The contact material is silver alloy, which enhances conductivity.
It is certified by CE, EN, IEC, RoHS, and UL standards.
The coil power rating is 200mW.
It is suitable for switching power in household appliances and industrial device outputs.
