Panasonic WE-GF 1210 Unshielded Wirewound Surface Mount Inductor with Ferrite Core 2.2μH ±10% 320mA 1Ω Resistance 74476402

Wurth Elektronik 74476402 WE-GF 1210 series unshielded wirewound surface mount inductors feature a ferrite core and provide an inductance of 2.2μH with ±10% tolerance. Designed for high frequency applications, these inductors support a maximum DC current of 320mA and have a maximum DC resistance of 1Ω. The surface mount 1210 package with dimensions 3.2mm length, 2.2mm height, and 2.5mm depth enables easy PCB integration in compact electronic devices.

Operating reliably within a temperature range of -40°C to 105°C, the WE-GF series is suitable for automotive and industrial electronic circuits. These inductors are intended for use in HF amplifiers, oscillators, transponders, LC filter circuits, adapter networks, and tuning circuits requiring stable inductance and low losses at higher frequencies.

The wirewound construction combined with a ferrite core ensures low core losses and high quality factor, with a minimum Q factor of 30. A maximum self-resonant frequency of 138MHz allows these inductors to perform effectively in demanding RF and high frequency circuitry.

Supplied in tape and reel packaging, these inductors are ready for automated placement and assembly, improving production efficiency. Compliance with RoHS and REACH standards confirms the product's adherence to environmental and safety regulations.

Ferrite core material for high-frequency efficiency. Wirewound inductor construction for durability and consistent performance. 1210 surface mount package compatible with standard PCB assembly. Wide operating temperature range from -40°C to 105°C.

RoHS and REACH compliant ensuring environmental safety. Maximum DC resistance of 1Ω to reduce power losses. Maximum current rating of 320mA for safe continuous operation. Inductance tolerance of ±10% for predictable circuit behavior.

Maximum self-resonant frequency of 138MHz for RF applications. High minimum quality factor of 30 for improved inductance quality.

This Wurth Elektronik WE-GF 1210 inductor series is ideal for industrial, automotive, telecommunications, and consumer electronics use. Enhance your PCB designs with these high quality Surface Mount Inductors that excel in HF circuits and filtering applications. Explore the Electronics Components category at EnvMart for a comprehensive range of inductors and passive components to support your engineering projects.
