Texas Instruments Operational Amplifier 2.2 MHz, 14-Pin SOIC, 8V TLC2274ID
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 8.65mm |
| Model | TLC2274ID |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TLC2274 |
| Output Current | 50mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 8V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 2.2MHz |
| Input Bias Current | 800 pA |
| Vos - Input Offset Voltage | 3 mV |
| Slew Rate | 3.6V/μs |
Key Features
- The device is a surface mount operational amplifier suitable for various electronics applications.
- It supports 4 channels with a pin count of 14.
- The input bias current is low at 800 pA, ensuring minimal signal distortion.
- Operating temperature ranges from -40°C to 125°C for automotive grade reliability.
- Features a slew rate of 3.6 V/μs for rapid response in signal processing.
- The input offset voltage is 3 mV ensuring precision performance.
- It complies with RoHS environmental standards for safe and eco-friendly use.
- Output current capability up to 50 mA meets demanding load requirements.
Product Description
Texas Instruments TLC2274ID is a high-performance, surface mount CMOS operational amplifier designed for commercial and automotive electronic applications. It offers a gain bandwidth product of 2.2 MHz and houses 4 independent amplifiers within a 14-pin SOIC package. The device operates over a supply voltage range from 5 V minimum to 8 V maximum, providing flexibility for various circuit designs.
With an input bias current of 800 pA and a low input offset voltage of 3 mV, the TLC2274ID ensures precise amplification with minimal error. Its slew rate of 3.6 V/μs allows rapid transitions, essential for fast signal processing. Rated to operate between -40°C and 125°C, this operational amplifier meets automotive standard AEC-Q100, guaranteeing reliability in harsh environments.
The compact physical dimensions of 8.65 mm length, 3.91 mm width, and 1.58 mm height make it ideal for densely packed printed circuit boards. Compliance with RoHS standards emphasizes its environmentally friendly manufacturing.
This Operational Amplifier supports output currents up to 50 mA, making it suitable for driving moderate loads in applications such as signal conditioning, analog computing, sensor interfacing, and industrial instrumentation.
Surface mount SOIC package with 14 pins featuring 4 independent channels. Gain bandwidth product of 2.2 MHz ensuring accurate frequency response. Wide operating voltage range from 5 V to 8 V for versatile use. Input bias current of 800 pA and offset voltage of 3 mV for precision.
Slew rate of 3.6 V/μs supports dynamic signal processing needs. Operating temperature from -40°C to 125°C adhering to automotive standards. RoHS compliant for eco-friendly electronic design. Output current capability up to 50 mA suitable for varied load requirements.
Ideal for use in industrial, laboratory, automotive, and electronic manufacturing environments, the TLC2274ID is a versatile and reliable component for advanced amplifier circuit designs. Explore more from Operating Amplifiers category at EnvMart for high-quality semiconductor products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 2.2 MHz, ensuring accurate frequency response for various applications.
It operates within a temperature range of -40°C to 125°C, making it suitable for automotive and harsh environment applications.
This operational amplifier features 4 independent channels, allowing for versatile circuit designs.
The TLC2274ID can provide an output current of up to 50 mA, suitable for driving moderate loads in various applications.
The input bias current is low at 800 pA, which helps ensure minimal signal distortion during amplification.
The input offset voltage is 3 mV, ensuring precision performance in signal amplification.
It has a slew rate of 3.6 V/μs, which supports rapid transitions in signal processing.
The TLC2274ID is housed in a 14-pin SOIC surface mount package, suitable for compact circuit designs.
It operates over a supply voltage range from 5 V to 8 V, providing flexibility for various circuit applications.
Yes, this operational amplifier complies with RoHS environmental standards, ensuring eco-friendly use.
It meets the AEC-Q100 automotive standard, ensuring reliability in automotive applications.
The dimensions of this model are 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height.
