Renesas Electronics Operational Amplifier 1.4 MHz, 8-Pin SOIC, Surface Mount, 3-8 V ICL7611DCBAZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Renesas Electronics |
| Height | 1.5mm |
| Length | 5mm |
| Model | ICL7611DCBAZ |
| Width | 4mm |
| Mount Type | Surface |
| Series | ICL76 |
| Output Current | 1mA |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 8V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1.4MHz |
| Input Bias Current | 400 pA |
| Vos - Input Offset Voltage | 20 mV |
| Slew Rate | 1.6V/μs |
| Input Offset Current | 30 pA |
Key Features
- Operates with a supply voltage range from 3 V to 8 V.
- Features a low input bias current of 400 picoamperes.
- Includes an input offset voltage of 20 millivolts and a slew rate of 1.6 V/µs.
- Designed to operate within 0°C to 70°C temperature range.
- Package dimensions are compact with a height of 1.5 mm, length of 5 mm, and width of 4 mm.
- 8-pin SOIC package suitable for surface mount applications.
- Offers a single channel operational amplifier function.
- Complies with RoHS standards.
Product Description
Renesas Electronics ICL7611DCBAZ operational amplifier is a precision analog integrated circuit designed for various industrial and electronic applications requiring low power consumption and stable performance.
This single-channel operational amplifier operates at a gain bandwidth product of 1.4 MHz and supports a supply voltage ranging from 3 V to 8 V, making it suitable for electronic circuits powered by low voltage sources.
The device is housed in an 8-pin SOIC surface mount package with compact dimensions (1.5 mm height, 5 mm length, and 4 mm width), facilitating integration in space-constrained PCB designs.
Key electrical characteristics include a low input bias current of 400 picoamperes, an input offset voltage of 20 millivolts, and a slew rate of 1.6 volts per microsecond, which ensures quick response and precision signal amplification. Its operating temperature ranges from 0°C up to 70°C, supporting moderate environmental conditions.
The amplifier is compliant with RoHS standards, ensuring environmental safety and regulatory compliance. With an output current capability of 1 mA and a minimal input offset current of 30 picoamperes, it suits applications demanding accuracy and reliability such as measuring instruments, sensor interfaces, and signal conditioning circuits.
Operates with a supply voltage range from 3 V to 8 V. Low input bias current ensures minimal signal distortion. Compact 8-pin SOIC package for efficient PCB layout. RoHS compliant for eco-friendly manufacturing. High slew rate enables fast signal processing.
Stable operation in typical industrial temperature range. Single channel amplifier ideal for precise analog applications. Low input offset voltage and current enhance measurement accuracy. Output current rating supports a variety of loads.
This operational amplifier from Renesas Electronics is well suited for industrial, laboratory, electronics manufacturing, sensors, and instrumentation sectors requiring high-quality analog signal processing components.
Explore more semiconductor Operational Amplifiers at EnvMart to match your specific design and application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This operational amplifier operates within a supply voltage range of 3 V to 8 V.
The gain bandwidth product for the ICL7611DCBAZ is 1.4 MHz.
It features a low input bias current of 400 picoamperes.
The input offset voltage is specified at 20 millivolts.
This model is designed to operate within a temperature range of 0°C to 70°C.
The package dimensions are 1.5 mm in height, 5 mm in length, and 4 mm in width.
It has an output current capability of 1 mA.
This operational amplifier is housed in an 8-pin SOIC surface mount package.
The slew rate is specified at 1.6 volts per microsecond.
Yes, it complies with RoHS standards, ensuring environmental safety.
The input offset current is 30 picoamperes.
It is suitable for applications such as measuring instruments, sensor interfaces, and signal conditioning circuits.
