Texas Instruments Operational Amplifier 22 MHz, 8-Pin SOIC, 4-18V OPA827AID

Texas Instruments OPA827AID is a precision operational amplifier belonging to the OPA827 series, featuring a high gain bandwidth of 22 MHz. It is housed in a compact 8-pin SOIC surface mount package suitable for modern electronic circuit designs.

This operational amplifier is designed with a JFET input stage that provides extremely low input bias and offset currents, making it ideal for high precision and low noise applications. It supports wide voltage supply operation from 4 V minimum to a maximum of 18 V, with a high slew rate of 28 V/μs enabling fast signal response.

The OPA827AID offers an output current capacity of 30 mA, suitable for driving moderate loads in industrial instrumentation, control systems, and laboratory measurement devices. With an operating temperature range from -40°C to 125°C, it performs reliably in harsh and varied industrial environments.

Gain bandwidth product of 22 MHz ensures accuracy and responsiveness in amplification. Input bias current of ±5 nA and input offset current of ±10 pA reduce signal distortion. Compact SOIC package (4.9 mm x 3.91 mm x 1.58 mm) facilitates high-density PCB layouts.

Wide supply voltage enables flexible system integration between 4 V to 18 V. High slew rate of 28 V/μs suits high-speed analog circuits. Robust operating temperature range supports various industrial and laboratory applications.

This operational amplifier is widely used in industrial electronics, laboratory instrumentation, precision data acquisition, and control equipment, providing superior performance for signal processing tasks.
