Texas Instruments Current Shunt Monitor Single Supply 2.7V to 18V 5-Pin SOT-23 INA195AIDBVT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.15mm |
| Length | 2.9mm |
| Model | INA195AIDBVT |
| Mount Type | Surface |
| Series | INA195 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 5 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 900μA |
| GBP - Gain Bandwidth Product | 200kHz |
| CMRR - Common Mode Rejection Ratio | 80dB |
Key Features
- Offers high common mode rejection ratio of 80 dB for precise current sensing.
- Operates with a low supply current of approximately 900 μA.
- Single channel device optimized for current shunt monitoring applications.
- Supports operating temperatures ranging from -40°C to 125°C for robust industrial use.
- Gain bandwidth product of 200 kHz enables accurate dynamic response.
- Surface mount package type SOT-23 with 5 pins for compact PCB designs.
- Compact dimensions of 2.9 mm length and 1.15 mm height enable space-saving implementations.
- No automotive certification, suitable for standard industrial and laboratory environments.
Product Description
Texas Instruments INA195AIDBVT Current Shunt Monitor is a precision amplifier designed for current sensing applications with a single power supply. This device operates within a supply voltage range of 2.7V to 18V, providing versatility across a variety of electronic circuits needing accurate current measurement.
The INA195AIDBVT offers an 80 dB common mode rejection ratio, reducing noise and interference for accurate sensing of shunt resistor voltage drops. With a supply current of only 900 μA, it ensures energy-efficient performance in portable and embedded electronics.
The amplifier operates with a gain bandwidth product of 200 kHz and comes in a compact 5-pin SOT-23 surface mount package, measuring 2.9 mm in length and 1.15 mm in height, making it suitable for space-constrained PCB layouts.
It is qualified to function in a wide temperature range from -40°C up to 125°C, thus suitable for industrial and laboratory environments requiring robust temperature tolerance. Although it does not carry automotive certification, the INA195 series is ideal for electronic power management, instrumentation, and monitoring systems.
High common mode rejection ratio of 80 dB for precise measurements. Low supply current of 900 μA enhances power efficiency. Single channel for focused current sensing tasks. Wide operating temperature range supports challenging environments.
Compact SOT-23 5-pin surface mount package dimensions enable space saving. Gain bandwidth product of 200 kHz ensures accurate dynamic response. This device is commonly used in industrial automation, embedded system design, laboratory instrumentation, and electronic component testing applications.
Explore more semiconductor solutions and precision Current Sensing Amplifiers in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The INA195AIDBVT operates within a supply voltage range of 2.7V to 18V.
It offers a common mode rejection ratio of 80 dB, which helps in reducing noise and interference for accurate current sensing.
The supply current is approximately 900 μA, enhancing power efficiency in applications.
The gain bandwidth product is 200 kHz, allowing for an accurate dynamic response in current sensing applications.
This model has compact dimensions of 2.9 mm in length and 1.15 mm in height, suitable for space-constrained PCB designs.
It operates effectively within a temperature range of -40°C to 125°C, making it suitable for industrial environments.
This model is a single channel device optimized for current shunt monitoring applications.
It comes in a 5-pin SOT-23 surface mount package, enabling compact PCB layouts.
No, it does not carry automotive certification and is intended for standard industrial and laboratory environments.
It is commonly used in industrial automation, embedded system design, laboratory instrumentation, and electronic component testing applications.
The mount type for this device is surface mount, which is suitable for compact electronic designs.
The INA195AIDBVT is manufactured in India.
