Nexperia 60 V 2.83 A Schottky Diode 2-Pin Surface Mount SOD-123W PMEG6020ELRX
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 2.8mm |
| Model | PMEG6020ELRX |
| Width | 1.9mm |
| Mount Type | Surface |
| Series | PMEG6020ELR |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-123W |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 2.83A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 300μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 760mV |
| Peak Reverse Recovery Time trr | 4.5ns |
| Average forward current | IF(AV) ≤ 2 A |
| Reverse voltage | VR ≤ 60 V |
Key Features
- Surface mount diode with SOD-123W package for compact PCB designs.
- Maximum continuous forward current of 2.83 A for reliable conduction.
- Peak reverse repetitive voltage rated at 60 V ensuring high voltage tolerance.
- Low forward voltage drop of 760 mV for improved efficiency.
- Extremely low leakage current of 300 μA to reduce power loss.
- Qualified to automotive AEC-Q101 standard for reliability.
- Operating temperature range from -55°C to 175°C for harsh environments.
- Fast reverse recovery time of 4.5 ns suitable for switching applications.
Product Description
Nexperia PMEG6020ELRX is a 60 V, 2.83 A low leakage Schottky barrier rectifier designed for efficient and reliable rectification in electronic circuits. Encapsulated in a small, flat SOD-123W surface-mounted plastic package, this diode integrates a guard ring for stress protection, ensuring robustness under electrical stress.
This Schottky diode features a planar maximum efficiency design optimized for low forward voltage drop and minimal power dissipation. It supports an average forward current (IF(AV)) of up to 2 A and reverse voltage (VR) up to 60 V. The device’s exceptionally low leakage current and high surge current capability make it suitable for demanding power supply circuits.
Its fast switching speed with a peak reverse recovery time of 4.5 ns supports high frequency DC-to-DC conversion and switching power supplies. The diode is qualified under the automotive AEC-Q101 standard, enabling use in automotive, industrial, and consumer electronics applications. The wide operating temperature range (-55°C to 175°C) ensures performance stability in harsh environments.
Surface mount SOD-123W package suitable for compact PCB layouts. Low forward voltage and leakage current reduce energy loss. High pulse surge current tolerates transient power spikes. Automotive grade reliability with AEC-Q101 qualification.
Ideal for reverse polarity protection and low power consumption applications. Typical uses include power supplies, DC-to-DC converters, reverse polarity protection, and general rectification tasks in automotive, industrial, and consumer electronic devices.
Explore more Schottky Diodes and semiconductor components with Nexperia on EnvMart for reliable electronic design solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 2.83 A, ensuring reliable conduction in applications.
This diode has a peak reverse repetitive voltage rating of 60 V, providing high voltage tolerance for various applications.
The maximum forward voltage drop for this unit is 760 mV, which contributes to improved efficiency in electronic circuits.
The operating temperature range for this model is from -55°C to 175°C, making it suitable for harsh environments.
This diode is encapsulated in a SOD-123W surface-mounted plastic package, ideal for compact PCB designs.
The peak reverse recovery time is 4.5 ns, which is suitable for high frequency DC-to-DC conversion and switching power supplies.
The maximum operating temperature for this model is 175°C, allowing it to function effectively in high-temperature environments.
It is qualified to the automotive AEC-Q101 standard, ensuring reliability for automotive applications.
The peak reverse current for this unit is rated at 300 μA, which helps reduce power loss in circuits.
The dimensions of this diode are 2.8 mm in length, 1.9 mm in width, and 1.1 mm in height.
This diode is suitable for applications including power supplies, DC-to-DC converters, and reverse polarity protection.
The average forward current rating for this model is up to 2 A, supporting efficient operation in various electronic circuits.
