Panasonic 12V dc Safety Relay PCB Mount SPNC SPNO Contact Configuration ASFM0122S
Specifications
| Country of Origin | Thailand |
|---|---|
| Power Consumption | 270mW |
| Brand | Panasonic |
| Height | 13.9mm |
| Length | 15.5mm |
| Model | ASFM0122S |
| Width | 33mm |
| Mount Type | PCB |
| Series | SFM |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPNC, SPNO |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder Pin |
| Standards/Approvals | RoHS |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 125V dc |
| Switching AC Voltage | 250V ac |
| Contact Current | 6A |
Key Features
- Operates at a coil voltage of 12V dc with low power consumption of 270mW.
- Features contact currents rated at 6A compatible with switching voltages up to 125V dc and 250V ac.
- Compact dimensions measuring 15.5mm length, 33mm width, and 13.9mm height.
- Wide operating temperature range from -40°C to 85°C for reliable performance in harsh environments.
- Compliant with RoHS standards ensuring environmentally responsible manufacturing.
- Suitable for integration in safety relay units, programmable logic controllers (PLC), robotics, and machine tool applications.
- Designed with solder pin terminals for secure PCB mounting.
- Manufactured in Thailand with flat type design for flux resistance and durability.
Product Description
Panasonic ASFM0122S is a 12V dc Safety Relay engineered for high-reliability industrial control applications. Its compact PCB mount design features SPNC and SPNO contact configurations that enable versatile circuit protection and switching roles.
The relay consumes a low power of 270mW at 12V dc coil voltage, making it energy efficient. It can manage contact currents up to 6A and switch DC voltages up to 125V as well as AC voltages up to 250V, supporting a broad range of control circuits.
Constructed to withstand tough environmental conditions, it operates reliably across a temperature span of -40°C to 85°C, meeting RoHS compliance to assure environmental safety.
Its compact size (15.5mm x 33mm x 13.9mm) and solder pin terminals allow seamless integration onto printed circuit boards used in safety relay units, PLCs, robotic controls, and various machine tools.
The flat type relay design offers flux resistance, enhancing stability and durability during manufacturing and operation in industrial and automation settings. Operates at a coil voltage of 12V dc with low power consumption of 270mW.
Contact configuration includes SPNC and SPNO types for flexible control schemes. Contact current rating of 6A with switching voltages of up to 125V dc and 250V ac. Compact dimensions of 15.5mm length, 33mm width, and 13.9mm height for PCB mounting.
Wide operating temperature range from -40°C to 85°C. RoHS compliant to meet environmental and safety standards. Designed for use in safety relay units, PLCs, robots, and machine tools. Manufactured in Thailand with flux-resistant flat type design.
This Panasonic ASFM0122S safety relay is ideal for industrial automation, electronic control panels, manufacturing safety systems, and robotics, providing reliable switching and protection under demanding conditions.
Explore a wide range of Safety Relays and industrial automation components at EnvMart for your specialized electrical and electronic control requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this safety relay is 12V DC.
It features SPNC (Single Pole Normally Closed) and SPNO (Single Pole Normally Open) contact configurations.
The maximum contact current rating is 6A.
It can switch DC voltages up to 125V and AC voltages up to 250V.
The power consumption is 270mW at the rated coil voltage.
The dimensions are 15.5mm in length, 33mm in width, and 13.9mm in height.
It operates reliably in a temperature range from -40°C to 85°C.
It is designed for PCB (Printed Circuit Board) mounting with solder pin terminals.
Yes, it is RoHS compliant, ensuring environmentally responsible manufacturing.
This safety relay is manufactured in Thailand.
It is suitable for integration in safety relay units, programmable logic controllers (PLCs), robotics, and machine tool applications.
It features a flat type design that offers flux resistance, enhancing stability and durability during operation.
