Molex Square Omni-Directional GNSS GPS Antenna with UFL/IPEX MHF Connector Adhesive Mount, 1558-1610MHz, 1.3dBi 206560-0150
Specifications
| Country of Origin | China |
|---|---|
| Brand | Molex |
| Connector Type | UFL/IPEX MHF |
| Bandwidth | 1610MHz |
| Series | 206560 |
| Gain | 1.3dBi |
| Lead Length | 0.15m |
| Standards/Approvals | CHINA RoHS, EU ELV, EU RoHS, REACH SVHC |
| Maximum Frequency | 1610MHz |
| Connector Gender | Female |
| Minimum Frequency | 1558MHz |
| Internal/External | Internal |
| RF Protocols | GPS |
| Antenna Physical Form | Square |
| Antenna Mount Type | Adhesive |
| Directivity | Omni-Directional |
| Number of Bands | 3 |
Key Features
- The antenna covers frequencies from 1558MHz to 1610MHz for GNSS including GPS, GLONASS, and BeiDou.
- Offers an omni-directional pattern with 1.3dBi gain for consistent signal reception.
- Features a square physical form with adhesive mounting for secure installation.
- Includes a 0.15m (150mm) cable with a female UFL/IPEX MHF connector.
- Complies with CHINA RoHS, EU ELV, EU RoHS, and REACH SVHC standards.
- Designed as an internal antenna suitable for various electronic applications.
- The compact and flexible GNSS flex antenna is from Molex's 206560 series.
Product Description
Molex 206560-0150 is a square shaped, omni-directional GNSS GPS antenna designed for reliable satellite signal reception from 1558MHz to 1610MHz. It supports multiple global navigation satellite systems including GPS, GLONASS, and BeiDou, making it suitable for diverse positioning and navigation applications.
The antenna is internally mounted using an adhesive backing for secure and permanent installation in electronic devices. Its physical form is compact and square-shaped, optimized for embedded use.
This model features a 0.15 meter (150mm) lead cable terminated with a female UFL/IPEX MHF connector, allowing easy connection to RF modules or circuit boards. The linear polarized antenna provides a gain of 1.3dBi and offers omni-directional directivity to maintain signal reception regardless of orientation.
The antenna covers a frequency range of 1558MHz to 1610MHz suitable for GNSS signals. Provides 1.3dBi gain with omni-directional directivity for consistent signal quality. Includes 150mm cable length with female UFL/IPEX MHF connector.
Adhesive mount type enables versatile internal mounting options. Complies with major global environmental standards. Part of Molex’s 206560 series of GNSS flex antennas. Compact square form factor perfectly fits embedded electronics.
This GPS antenna is ideally suited for industrial, automotive, consumer electronics, and communication equipment applications requiring precise global positioning and satellite navigation.
For professionals seeking high-quality, compliant GNSS antennas, Molex 206560-0150 offers a reliable solution with ease of integration. Explore more GPS antennas and electronic components in the Electronics & Electricals category on EnvMart for industrial and commercial use cases.
Explore more products in our Passive Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It features a female UFL/IPEX MHF connector for easy connection to RF modules or circuit boards.
This model uses an adhesive mount type, allowing for secure and permanent installation in electronic devices.
The antenna has a square physical form, optimized for embedded use in various applications.
The antenna includes a 0.15 meter (150mm) lead cable.
It complies with CHINA RoHS, EU ELV, EU RoHS, and REACH SVHC standards.
This unit features omni-directional directivity, allowing for reliable signal reception regardless of orientation.
This model is part of Molex's 206560 series of GNSS flex antennas.
It is designed as an internal antenna, suitable for various electronic applications.
This antenna is ideally suited for industrial, automotive, consumer electronics, and communication equipment applications requiring precise global positioning and satellite navigation.
