Panasonic PhotoMOS Series Solid State Relay 1.2 A Load 60 V Load Surface Mount AQY222R2T

Panasonic AQY222R2T PhotoMOS Series Solid State Relay is a high-performance electronic switching device designed for industrial and automation applications. Featuring a miniature VSSOP package, this relay supports a maximum load current of 1.2 A and a load voltage rating of 60 V, suitable for compact circuit designs requiring efficient power switching.

The device provides AC/DC switching capabilities with SPST (Single Pole Single Throw) contact configuration, offering versatile use in signaling, control, and switching circuits. Its low on state resistance of 1.25 milliohms reduces power loss and heat generation, making it ideal for energy-conscious designs.

Designed to operate over a broad temperature range from -40°C to 85°C, it ensures reliable performance in various industrial environments. The off state leakage current is kept to a minimum at 10 nanoamperes, enhancing overall circuit efficiency. Low output capacitance of 1.5 pF facilitates fast switching and minimizes signal distortion.

Its through hole terminal type ensures sturdy and reliable connections in PCB mounting. The MOSFET output type delivers rapid response times and excellent switching characteristics required for modern electronic applications. The product is RoHS compliant, reflecting adherence to environmental regulations and sustainable manufacturing practices.

Manufactured in Japan, the AQY222R2T solid state relay exemplifies Panasonic’s commitment to quality and innovation. Typical applications include industrial control systems, laboratory instrumentation, testing equipment, HVAC systems, and manufacturing automation processes where compact, high-reliability switching solutions are critical.

Compact and low-profile VSSOP package for space-saving designs. Supports both AC and DC switching for flexible applications. Low on state resistance minimizes power dissipation. Wide operating temperature range for harsh industrial environments.

Low leakage current improves energy efficiency in circuits. Quick switching enabled by low output capacitance. Reliable through-hole mount terminals ensure mechanical stability. MOSFET output enhances switching speed and durability.

RoHS compliant manufacturing ensures environmental safety. Made in Japan, guaranteeing high product quality. Explore more Panasonic Solid State Relays and related components at EnvMart for your electronic system design requirements.
