ERNI 2-Way IDC Connector for Surface Mount, 2 Row, 17.5A Current 454302 / 454302-E
Specifications
| Country of Origin | India |
|---|---|
| Brand | ERNI |
| Orientation | Straight |
| Current | 17.5A |
| Model | 454302 / 454302-E |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper |
| Termination Type | IDC |
| Maximum Operating Temperature | 150.0°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Contact Plating | Tin |
| Number of Contacts | 2 |
Key Features
- Designed for surface mount PCB applications with a compact 2-row configuration.
- Enables gas tight permanent electrical connections with IDC contacts.
- Supports stranded wire size AWG 22/7 with feed through configuration.
- No wire preparation or hand soldering required, reducing assembly time.
- Constructed with copper contacts and Liquid Crystal Polymer housing for durability.
- Wide operating temperature range from -55°C to 150°C for versatile environments.
- Straight orientation with tin-plated contacts ensures reliable signal integrity.
- Suitable for automated board assembly in industrial and electronic applications.
Product Description
ERNI 454302 / 454302-E is a high-quality 2-way IDC connector designed for surface mount PCB applications featuring two rows. It supports a current rating of 17.5 amperes and provides a compact, microminiature SMT design that saves valuable PCB space. This connector utilizes insulation displacement contact (IDC) technology to establish gas tight and permanent electrical connections without requiring wire preparation or hand soldering.
The connector features copper contacts plated with tin, housed in a liquid crystal polymer body for enhanced durability and temperature resistance. It operates reliably within a temperature range of -55°C to 150°C, making it suitable for varied industrial, medical, mobile device, smart metering, and retrofit LED lighting applications.
The straight orientation and feed-through configuration support stranded wire AWG 22/7, simplifying harness assembly. With guiding latches and detents, it ensures accurate insertion and secure holding of wires, eliminating the need for special tooling. This makes the ERNI IDC connector an ideal choice for automated assembly lines and cost-effective production.
Designed for surface mount PCB applications with a compact 2-row configuration. Enables gas tight permanent electrical connections with IDC contacts. Supports stranded wire size AWG 22/7 with feed through configuration. No wire preparation or hand soldering required, reducing assembly time.
Constructed with copper contacts and Liquid Crystal Polymer housing for durability. Wide operating temperature range from -55°C to 150°C for versatile environments. Straight orientation with tin-plated contacts ensures reliable signal integrity.
Suitable for automated board assembly in industrial and electronic applications. Microminiature design saves PCB space while maintaining robust connectivity.
This connector is optimally used in industrial, electronic components, power and connectors sectors where reliable, compact, and easy-to-assemble wire-to-board connections are critical. The microminiature IDC technology reduces assembly costs and complexity, enhancing product reliability across applications such as medical equipment, mobile devices, smart metering, and retrofit LED lamps.
Explore other ERNI IDC Connector options for additional configurations and mounting types at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 17.5 amperes, making it suitable for various applications requiring reliable electrical connections.
It operates within a wide temperature range from -55°C to 150°C, allowing it to function effectively in diverse environments.
This connector is designed for surface mounting on PCBs, which facilitates easy integration into electronic assemblies.
It features copper contacts plated with tin and is housed in a liquid crystal polymer body, ensuring durability and reliability.
This model has a compact 2-row configuration, optimizing PCB space while providing effective connectivity.
It supports stranded wire sizes of AWG 22/7, making it versatile for various wiring needs in applications.
No wire preparation or hand soldering is required, which significantly reduces assembly time and complexity.
This model utilizes insulation displacement contact (IDC) technology for establishing electrical connections without the need for soldering.
It is suitable for industrial, medical, mobile device, smart metering, and retrofit LED lighting applications due to its reliable performance.
The connector features a straight orientation, which aids in straightforward installation on PCBs.
This model has 2 contacts, allowing for effective electrical connections in its compact design.
The country of origin for this connector is India, indicating its manufacturing location.
