Texas Instruments Operational Amplifier 1 MHz, 14-Pin Through Hole CDIP Package LM124J/PB

Texas Instruments LM124J/PB is a precision operational amplifier designed for robust performance in industrial, laboratory, and electronic circuit applications. Featuring a gain bandwidth product of 1 MHz and packaged in a 14-pin CDIP through hole mount, this amplifier provides excellent parameter stability and ease of installation.

The LM124J/PB offers four channels in a single integrated circuit, making it ideal for compact and efficient multiple amplifier requirements. Its input offset voltage of just 2 mV, combined with low input bias and offset currents, ensures accurate signal amplification and low drift over temperature.

Operating voltage ranges from 3V to 32V with an output current capability of 20 mA, allowing it to drive a variety of loads while maintaining signal integrity. Its wide operating temperature range from -55°C to 125°C means it is suitable for use in demanding electrical environments including industrial automation, instrumentation, and automotive electronics.

The package dimensions of 19.94 mm length, 7.19 mm width, and 5.08 mm height facilitate easy incorporation into PCB designs using standard through hole mounting techniques. Although no specific automotive certification is provided, the chip is built for durable semiconductor performance within varied electronic systems.

The device features a gain bandwidth product of 1 MHz ensuring reliable performance. It has four channels in a single package, enhancing integration and design efficiency. Input offset voltage is low at 2 mV for precision amplification.

Operating voltage ranges from 3V minimum up to 32V maximum. Wide operating temperature range from -55°C to 125°C supports harsh environment usage. Output current capability is up to 20 mA for driving loads effectively. Compact dimensions include length 19.94 mm, width 7.19 mm, and height 5.08 mm.

Designed with through hole mount type and housed in a CDIP package for ease of PCB assembly.

This Operational Amplifier is commonly used in electronics manufacturing, laboratory instrument designs, and industrial control systems. It is well-suited for engineers and designers seeking reliable analog amplification in a multi-channel, compact format.
