Texas Instruments Operational Amplifier 10 MHz 8-Pin 36V SOIC OPA2172ID

Texas Instruments OPA2172ID is a dual channel operational amplifier designed for high precision and high speed applications. It features a 10 MHz gain bandwidth product ensuring efficient amplification of signals in demanding environments.

This device comes in an 8-pin SOIC surface mount package, making it ideal for compact and high-density PCB assemblies. It supports a wide supply voltage range from 4.5 V to 36 V, providing flexibility across different power systems.

The OPA2172ID offers a low input offset voltage of ±1 mV and low input bias current of ±14 nA, which contributes to precise signal conditioning. The input offset current is at 3 nA, further enhancing signal integrity in sensitive measurements.

Its fast slew rate of 10 V/μs enables rapid response to dynamic signals, suitable for audio, instrumentation, and control systems. The amplifier is rated for operation in harsh temperature ranges from -40°C to 125°C, meeting automotive standard AEC-Q100 for reliability in automotive and industrial uses.

Physical dimensions of the amplifier package are compact at 3.05 mm length, 1.75 mm width, and 1.45 mm height, facilitating integration into space-constrained designs. Surface mount type suitable for high-density PCB designs.

Dual channel operational amplifier with 8 pins for compactness. Gain bandwidth product of 10 MHz for high frequency applications. Wide operating voltage range from 4.5 V to 36 V. Low input offset voltage of ±1 mV for precision performance.

Input bias current of ±14 nA and input offset current of 3 nA. High slew rate of 10 V/μs for fast signal response. Operating temperature range from -40°C to 125°C for robustness. Compliance with automotive standard AEC-Q100 ensuring reliability.

Compact size with length 3.05 mm, width 1.75 mm, and height 1.45 mm.

This operational amplifier is suitable for use in industrial, automotive, electronics manufacturing, instrumentation, and laboratory applications requiring precision analog signal amplification. Its robust specifications and compliance with industry standards guarantee dependable performance in critical electronic systems.
