Omron Multifunction Panel Timer Relay 0.1 to 2.4s, DPDT Switch, 100-240V AC, 125V DC, Panel Mount H3CR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Omron |
| Height | 81.6mm |
| Function | Multifunction |
| Length | 48mm |
| Model | H3CR |
| IP Rating | IP40 |
| Mode | Multifunction |
| Width | 48mm |
| Mount Type | Panel |
| Series | H3CR |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -10°C |
| Time Range | 0.1 → 2.4 s |
| Terminal type | 11-Pin |
| Standards/Approvals | Lloyds, CE, UL508, CCC, NK, IEC60664-1, CSA C22.2 No.14, EN61812-1 |
| Number of Timer Functions | Multifunction |
| Switching Voltage | 250V |
| Contact Current | 5A |
| Supply DC Voltage | 125 V |
| Timing Adjustment | Knob |
| Supply AC Voltage | 100, 240V ac |
Key Features
- Supports multifunction timing for versatile control applications.
- Wide voltage range of 100 - 240V AC and 125V DC for flexible installation.
- DPDT contacts rated at 5A suitable for various moderate load switching.
- Panel mount design with compact dimensions of 48x48x81.6 mm for dense control panels.
- Operating temperature range from -10°C to 55°C ensuring reliable performance.
- Knob adjustment enables quick and easy on-site time setting.
- 11-pin terminal configuration for simple wiring and replacement.
- Complies with multiple international standards including UL508, CE, and IEC60664-1.
Product Description
Omron H3CR-A-301 100-240AC/100-125DC is a multifunction panel timer relay designed for precise timing control in industrial automation and electrical systems. It supports adjustable time intervals from 0.1 to 2.4 seconds and features DPDT contact configuration for reliable switching.
This panel mount device operates over a wide voltage supply range of 100 to 240 V AC and 125 V DC, simplifying inventory requirements and installation versatility. Its compact dimensions of 48mm width, 48mm length, and 81.6mm height allow efficient use of panel space in control cabinets and machinery.
Equipped with 11-pin terminals, the relay ensures easy wiring, maintenance, and replacement. The knob adjustment mechanism provides rapid on-site timing setup without the need for special tools. Rated contact current at 5A and a switching voltage capacity of 250V make it suitable for controlling moderate electrical loads in varied applications.
Operating reliably in ambient temperatures from -10°C up to 55°C, it meets industry standards including Lloyds, CE, UL508, CCC, NK, IEC60664-1, CSA C22.2 No.14, and EN61812-1, confirming its quality and safety for diverse uses.
Typical uses include sequenced start/stop control in machinery panels, delay functions in conveyor and batching systems, timed control for HVAC and process equipment, and lamp or motor run-on control. Its multifunction capabilities allow integration into complex automation sequences effectively.
Supports multifunction timing for varied control schemes. Wide supply range accommodates both AC and DC voltages. DPDT contacts provide reliable switching of moderate loads. Knob adjustment enables easy and fast timing changes.
Compact panel mount design for space-efficient installation. Robust operation in wide temperature range for industrial environments. Compliant with multiple international safety and performance standards. 11-pin terminal supports straightforward wiring and replacement.
Explore EnvMart’s collection of high-performance Timer Relays, including Omron products, for your industrial automation and control needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a timing range from 0.1 to 2.4 seconds, allowing for precise control in various applications.
It features a DPDT (Double Pole Double Throw) contact configuration, suitable for reliable switching of moderate loads.
The timer relay operates reliably within an ambient temperature range of -10°C to 55°C, making it suitable for diverse industrial environments.
It accepts a wide voltage supply range of 100 to 240V AC and 125V DC, providing flexibility for installation.
The dimensions are 48mm in width, 48mm in length, and 81.6mm in height, allowing for efficient use of panel space.
Timing adjustments are made using a knob, enabling quick and easy on-site setting without special tools.
The relay is rated for a contact current of 5A, suitable for various moderate load switching applications.
It complies with multiple international standards including UL508, CE, and IEC60664-1, ensuring quality and safety.
This unit features an 11-pin terminal configuration, which simplifies wiring and replacement processes.
The switching voltage capacity is 250V, making it suitable for controlling moderate electrical loads.
Typical applications include sequenced start/stop control in machinery panels, delay functions in conveyor systems, and timed control for HVAC equipment.
The country of origin for this timer relay is India.
