Molex Square Omni-Directional 6-Band GSM & GPRS Antenna with UFL-Type Micro-Coaxial Connector 3dBi Gain 105263-0003
Specifications
| Country of Origin | India |
|---|---|
| Brand | Molex |
| Operating Temperature | -30 to +75°C |
| Connector Type | UFL-Type Micro-Coaxial |
| Series | 105263 |
| Input Impedance | 50 Ohms |
| Polarization | Linear |
| Gain | 3dBi |
| Lead Length | 0.2m |
| Standards/Approvals | EU, REACH, RoHS |
| Minimum Frequency | 824MHz |
| Internal/External | Internal |
| Antenna Physical Form | Square |
| Antenna Mount Type | Adhesive |
| Directivity | Omni-Directional |
| Number of Bands | 6 |
| Max PWR | 2 W / 33 dBm |
Key Features
- Supports 6 cellular bands including GSM and LTE frequencies.
- Compact square design with adhesive mounting.
- 3 dBi gain and omni-directional coverage for effective signal propagation.
- Flexible micro-coaxial lead with UFL connector included.
- Wide operating temperature range from -30 to +75°C.
- Complies with EU RoHS and REACH environmental standards.
- Suitable for industrial, medical, and wireless communication applications.
- Provides reflection coefficient better than -7 dB over supported bands.
Product Description
The Molex 105263-0003 is a square, omni-directional antenna designed for GSM and GPRS cellular communications across six key wireless bands including GSM850, GSM900, GSM1800, GSM1900, UMTS band-1, and LTE band-7. This internal antenna provides reliable performance with a 3 dBi gain and is equipped with a UFL-type micro-coaxial connector and a 0.2 meter lead, making it suitable for compact installations.
Its adhesive mount allows for straightforward application on flat surfaces, supported by a poly-flexible adhesive tape on the underside. The antenna's construction ensures a reflection coefficient better than -7 dB and radiation efficiencies of approximately 80% at lower GSM bands and 70% at higher frequency bands, enhancing signal quality and reliability.
Operating within a temperature range of -30 to +75 degrees Celsius, this antenna is suitable for diverse industrial, medical, and wireless communication applications where space and dependable coverage are essential. The device is compliant with EU RoHS and REACH directives, ensuring environmentally friendly manufacturing and use.
With an input impedance of 50 Ohms and linear polarization, this antenna supports a maximum input power of 2 Watts (33 dBm). Its omni-directional pattern offers broad signal reception and transmission suitable for multiple bands, facilitating seamless cellular communication in GSM and LTE networks.
Supports 6 cellular bands including GSM and LTE frequencies. Compact square design with adhesive mounting. 3 dBi gain and omni-directional coverage for effective signal propagation. Flexible micro-coaxial lead with UFL connector included.
Wide operating temperature range from -30 to +75°C. Complies with EU RoHS and REACH environmental standards. Suitable for industrial, medical, and wireless communication applications.
The Molex 105263-0003 antenna is an ideal choice for engineers and installers requiring compact, versatile GSM and LTE band antennas with easy mounting and high performance. Browse the complete range of GSM & GPRS antennas and Molex components on EnvMart for reliable wireless connectivity solutions.
Explore more products in our Passive Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a gain of 3 dBi, providing effective signal propagation for cellular communications.
It supports six cellular bands including GSM850, GSM900, GSM1800, GSM1900, UMTS band-1, and LTE band-7.
The operating temperature range is from -30 to +75 degrees Celsius, making it suitable for various environments.
It is equipped with a UFL-type micro-coaxial connector, allowing for compact installations.
This model features an adhesive mount, which allows for straightforward application on flat surfaces.
The input impedance is 50 Ohms, which is standard for many antenna applications.
It supports a maximum input power of 2 Watts (33 dBm).
The antenna has a square physical form, designed for internal applications.
The antenna provides a reflection coefficient better than -7 dB over the supported bands, enhancing signal quality.
It is suitable for industrial, medical, and wireless communication applications, where compact and reliable coverage is needed.
This model complies with EU RoHS and REACH environmental standards, ensuring environmentally friendly manufacturing.
The antenna has radiation efficiencies of approximately 80% at lower GSM bands and 70% at higher frequency bands.
