Radiall Through Hole High Frequency Relay 12V DC Coil 5W Power SPDT Contact Configuration R516332100
Specifications
| Country of Origin | India |
|---|---|
| Frequency | Relay, 12V dc Coil, 8 GHz Max |
| Brand | Radiall |
| Height | 12mm |
| Length | 15mm |
| Model | R516332100 |
| Mount Type | Through Hole |
| Isolation | 40dB |
| Contact Material | Copper |
| Series | QUARTZ SMT |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder Pin |
| Standards/Approvals | RoHS |
| Coil Resistance | 205Ω |
| Coil Power | 5W |
| Insertion Loss | 0.5dB |
| Maximum Coil Frequency | 8GHz |
Key Features
- The relay supports a maximum coil frequency of 8 GHz for high frequency signal switching.
- It has a coil resistance of 205 ohms and coil power rating of 5W.
- Insertion loss is minimal at 0.5dB, ensuring signal integrity.
- Isolation between contacts reaches up to 40dB for noise reduction.
- The device uses copper contacts and solder pin terminals for reliable connection.
- Mount type is through hole compatible with standard PCB designs.
- Operating temperature range spans from -40°C to 85°C for industrial environments.
- Compact dimensions of 15mm length and 12mm height enable space-efficient integration.
Product Description
Radiall R516332100 Through Hole High Frequency Relay with 12V DC Coil and 5W coil power is designed for RF applications up to 8 GHz. This SPDT relay uses proven RAMSES and SLIM LINE technology to provide high frequency operation with typical life of 5 million cycles.
The relay features a coil resistance of 205 ohms, solder pin terminals, and copper contacts for optimal performance. Its through-hole mount type facilitates secure PCB integration in industrial, laboratory, telecommunications, and automated systems.
The device offers minimal insertion loss of 0.5dB and high isolation of 40dB, essential for maintaining signal fidelity in high frequency circuits. Operating temperature ranges from -40°C to 85°C, supporting robust operation under varied environmental conditions.
Compact dimensions of 15mm length and 12mm height make it suitable for space-constrained applications. This relay is RoHS compliant, adhering to environmental and safety standards.
Part of the QUARTZ SMT series, this relay is ideal for high power and high repeatability applications in microwave, RF communication, industrial automation, and measurement instrumentation.
The relay supports a maximum coil frequency of 8 GHz for high frequency signal switching. It has a coil resistance of 205 ohms and coil power rating of 5W. Insertion loss is minimal at 0.5dB, ensuring signal integrity. Isolation between contacts reaches up to 40dB for noise reduction.
The device uses copper contacts and solder pin terminals for reliable connection. Mount type is through hole compatible with standard PCB designs. Operating temperature range spans from -40°C to 85°C for industrial environments.
Compact dimensions of 15mm length and 12mm height enable space-efficient integration. Complies with RoHS standards ensuring environmental safety. Part of the QUARTZ SMT series optimized for long life and high repeatability.
Explore more high frequency relay products at EnvMart for industrial, telecom, and laboratory automation needs.
Explore more products in our HF & RF Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay supports a maximum coil frequency of 8 GHz for high frequency signal switching.
The coil resistance of this model is 205 ohms.
The insertion loss is minimal at 0.5dB, ensuring signal integrity in high frequency applications.
Isolation between contacts reaches up to 40dB, which helps in noise reduction.
The relay has compact dimensions of 15mm in length and 12mm in height.
It uses a through hole mount type, compatible with standard PCB designs.
The operating temperature range spans from -40°C to 85°C, suitable for industrial environments.
This relay features a Single Pole Double Throw (SPDT) contact configuration.
The device uses copper contacts for reliable connection.
The coil power rating is 5W.
Yes, this relay complies with RoHS standards, ensuring environmental safety.
This relay is part of the QUARTZ SMT series, optimized for long life and high repeatability applications.
