Radiall MCX Series Coaxial Connector Through Hole Female MCX 50 Ω Right Angle Body Solder R113665000W

Radiall R113665000W MCX Series Coaxial Connector is a high-performance industrial-grade connector designed for reliable signal transmission in communication and electronic equipment. This female MCX connector features a right angle body and is designed for through hole mounting on printed circuit boards, facilitating compact and secure PCB layouts.

The connector supports a nominal impedance of 50 Ω and operates effectively at frequencies up to 6 GHz, making it suitable for high-frequency applications in industrial, laboratory, and military communication systems. Its body and contacts are plated with gold over nickel, enhancing corrosion resistance and ensuring long-term durability under demanding conditions.

Constructed from beryllium copper, the contact material combines excellent conductivity with mechanical strength. The connector is rated to withstand temperature extremes from -55°C to 155°C, allowing use in harsh environments including outdoor or high-temperature industrial settings. Its bulkhead mount provides additional mechanical stability when installed on panels or equipment housings.

With a rapid push-pull snap-on mating action compatible with other 75 Ω variants, the Radiall MCX connector series offers efficient assembly and maintenance. Its smaller size compared to SMB connectors allows integration into equipment with limited space. The solder termination type ensures a robust and permanent electrical connection for board-level applications.

Coaxial connector type MCX with quick push-pull snap-on mating action. Right angle female connector with through hole mount for PCB integration. Gold over nickel plating provides excellent corrosion resistance. Operating frequency up to 6 GHz with 50 Ω impedance.

Beryllium copper contact material for durability and conductivity. Operating temperature range from -55°C to 155°C suitable for harsh environments. Bulkhead mount secure installation on panels and housings. Standard size MCX connector for compact device designs.

Solder termination type ensures reliable electrical connection. Normal polarity with female contact gender matching male counterparts.

This connector is widely used in industrial manufacturing, communication systems, laboratory instrumentation, HVAC controls, and military applications requiring reliable high-frequency coaxial connections. For more options and detailed technical documents, explore the Coaxial Connector category at EnvMart.
