Radiall Through Hole High Frequency Relay 24V DC Coil 5W 8 GHz Max Coil Frequency SPDT R516393100

Radiall R516393100 through hole high frequency relay features a 24V DC coil with 5W coil power, designed for high frequency RF applications with a maximum coil frequency of 8 GHz. This relay utilizes a single pole double throw (SPDT) contact configuration and through hole mounting with solder pin terminals, providing robust and reliable electrical connections.

The relay is constructed with copper contact material, delivering excellent conductivity and durability essential for precision switching in electronic circuits. It offers a low insertion loss of 0.5 dB and high isolation of 40 dB, ensuring minimal signal interference and optimal performance in high frequency environments.

The operating temperature range of -25°C to 70°C allows this relay to function efficiently in various industrial and commercial settings. Its compact size, measuring 15 mm in length and 12 mm in height, makes it ideal for space-constrained electronic designs.

This Radiall Quartz SMT series relay extends the frequency range limits of previous SMT switches by merging the RAMSES concept with SLIM LINE technology, delivering a typical operating life of 5 million cycles. These surface mount relays excel in applications demanding high frequency performance where size and reliability are critical.

Applications include RF communication devices, test and measurement equipment, industrial control systems, and automated manufacturing processes requiring precise and durable high frequency switching components. Compliance with RoHS standards confirms the relay's adherence to environmental and safety requirements.

High frequency operation suitable for RF applications up to 8 GHz. Through hole mounting with solder pin terminals for reliable connections. Single pole double throw (SPDT) contact configuration for versatile switching. Coil resistance of 740 ohms ensuring stable coil performance.

Low insertion loss of 0.5 dB and high isolation of 40 dB for signal integrity. Copper contact material for durability and high conductivity. Operating temperature range from -25°C to 70°C for varied environments. Compact dimensions: length 15 mm and height 12 mm for space-constrained designs.

Meets RoHS standards for hazardous substances compliance. Part of the Quartz SMT series with extended frequency range and high repeatability.

Choose Radiall R516393100 for dependable high frequency relay performance in demanding industrial and electronic applications. Explore the full range of HF & RF relays at EnvMart for comprehensive switching solutions.
