Tektronix 200 MHz Bench Mixed Domain Oscilloscope, 2 Channels, 9 in TFT LCD Screen MDO3000

Tektronix MDO3022 is a 200 MHz bench mixed domain oscilloscope designed for advanced testing and analysis in industrial, laboratory, and manufacturing environments. Featuring two channels and a large 9 inch TFT LCD screen, it delivers precise waveform visualization and versatile signal capture capabilities.

This oscilloscope integrates basic spectrum analyzer functions, Wave Inspector Navigation, MSO capabilities, along with serial and parallel bus triggering and analysis, fulfilling the needs for mixed domain testing. The device supports multiple interface protocols including CAN, LIN, RS232, RS422, RS485, SPI, UART, and USB, enhancing communication flexibility in complex systems.

With a minimum time base of 1 ns/div and rise time of 1.75 ns, the MDO3022 captures rapid signal transitions accurately. The vertical resolution of 8 bit offers high fidelity in signal representation. Operating from mains power, the instrument complies with RoHS standards, ensuring it meets environmental directives.

The scope supports optional upgrades like arbitrary function generation, mixed signal analysis with 16 channels, enhanced spectrum analyzer ranges, and specialized serial bus triggering modules. It is supplied with a passive voltage probe (TPP0250) for each channel, N-to-BNC adapters, power cord, accessory bag, and calibration certificates.

Ideal applications include electronic development, embedded system debugging, automotive communication analysis, aerospace testing, and power analysis. It serves well in industrial, laboratory, HVAC, manufacturing, water treatment, agricultural, and commercial sectors requiring high precision oscilloscopes.

200 MHz bandwidth allows detailed signal analysis. Two input channels enable multiple signal recordings simultaneously. 9 inch TFT LCD screen provides clear signal visualization. Mixed domain architecture supports time and frequency domain analyses.

Multiple communication interfaces increase flexibility for complex systems. Fast 1 ns/div time base and 1.75 ns rise time capture transient events accurately. Vertical sensitivity range 1 mV/div to 10 V/div accommodates varied signal magnitudes.

Compliant with RoHS environmental regulations. Supplied with passive voltage probes and accessories for immediate use. Upgradeable modules extend functionality as needed. Explore more Oscilloscopes and measurement instruments at EnvMart to meet your test and instrumentation needs.
