DiodesZetex High Side Current Monitor 3-Pin SOT-23 Package 2.5-20V 2MHz Bandwidth ZXCT1008FTA

DiodesZetex ZXCT1008FTA is a high side current monitor integrated circuit supplied in a 3-pin SOT-23 package. It operates at a minimum supply voltage of 2.5V up to 20V with a 2MHz bandwidth, making it suitable for fast and precise current sensing in electronic circuits.

Featuring a very low quiescent current of 4μA, this device is optimized for low power consumption applications. The SOT-23 surface mount package dimensions of 3.04mm length and 1.02mm height allow for compact placement in printed circuit boards.

Capable of operating within a temperature range of -40°C to 85°C, the ZXCT1008FTA is well suited for industrial and automotive environments, although it does not have specific automotive certification. This current sensing amplifier provides a voltage output proportional to the voltage drop across a low value resistor positioned in high current power rails, enabling effective current measurement and monitoring.

The device draws only 4μA quiescent current. It comes in a compact SOT-23 package of 3.04mm by 1.02mm. Surface-mountable design for efficient PCB integration. Wide operating voltage range from 2.5V to 20V. Operational temperature range from -40°C to 85°C for harsh environments.

Conforms to RoHS directive ensuring restricted hazardous substances compliance. Suited for power system monitoring, industrial machinery, and instrumentation. Country of Origin: Germany. Explore more products in the Current Sensor ICs category on EnvMart for your electronic component needs.
