DiodesZetex Switching Diode, Single, 3 A, 2-Pin Surface Mount SMB Package, 200 V ES3DB-13-F
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 2.3mm |
| Length | 4.57mm |
| Model | ES3DB-13-F |
| Width | 3.94mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SMB |
| Sub Type | Silicon Junction |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Diode Configuration | Single |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 900mV |
| Peak Reverse Recovery Time trr | 25ns |
| Maximum Forward Current If | 3A |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 200V |
Key Features
- Maximum forward current of 3 amperes ensuring reliable performance in switching applications.
- Surface mount SMB package with dimensions approximately 4.57 mm length, 3.94 mm width, and 2.3 mm height.
- Maximum peak reverse repetitive voltage of 200 volts provides high voltage tolerance.
- Fast switching with a peak reverse recovery time of 25 nanoseconds for efficient electronic circuits.
- Operating temperature range from -55°C to 150°C suitable for harsh industrial environments.
- Maximum forward voltage drop of 900 millivolts reduces power loss during conduction.
- Peak non-repetitive forward surge current of 100 amperes allowing surge tolerance during transient events.
- Package designed for surface mounting to enable compact and automated PCB assembly.
Product Description
DiodesZetex ES3DB-13-F is a high-quality single silicon junction switching diode designed for industrial and electronic applications requiring efficient switching performance. Packaged in a surface mount SMB outline, it features a 2-pin configuration enabling easy PCB mounting and automated installation, supporting modern electronics manufacturing processes.
This diode supports a maximum forward current of 3 amperes and can withstand up to 200 volts peak reverse repetitive voltage, making it suitable for power management and protection circuits. With a low forward voltage of 900 millivolts, it minimizes conduction losses in electronic circuits, improving overall efficiency.
The ES3DB-13-F diode possesses a very fast peak reverse recovery time of 25 nanoseconds, allowing rapid switching necessary in high-frequency applications such as power supplies and switching regulators. Its operational temperature range of -55°C to 150°C ensures reliable function across extreme environmental conditions, ideal for robust industrial and automotive systems.
Additionally, the diode can sustain surge currents up to 100 amperes briefly, providing resilience against transient currents commonly encountered in real-world electrical environments. Its SMB package dimensions of approximately 4.57 mm length, 3.94 mm width, and 2.3 mm height allow compact circuit layouts without compromising performance.
Manufactured in China under strict quality controls by DiodesZetex, this diode is engineered for durability and consistent performance. It finds application in discrete semiconductor switching diode roles, commonly used in electronic devices, power converters, and signal conditioning circuits.
Maximum forward current: 3 A. Peak reverse voltage: 200 V. Forward voltage drop: 0.9 V max. Peak reverse recovery time: 25 ns. Operating temperature: -55°C to 150°C. Surface mount SMB package. 2-pin configuration. Peak surge current: 100 A.
Explore more electronic components and Switching Diodes from DiodesZetex at EnvMart to suit your industrial and laboratory needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward current of the ES3DB-13-F diode is 3 amperes.
This model has a peak reverse repetitive voltage rating of 200 volts.
The SMB package dimensions are approximately 4.57 mm in length, 3.94 mm in width, and 2.3 mm in height.
The peak reverse recovery time is 25 nanoseconds, allowing for efficient switching in electronic circuits.
It operates within a temperature range of -55°C to 150°C, making it suitable for harsh environments.
The maximum forward voltage drop is 900 millivolts, which helps reduce power loss during conduction.
The diode can handle a peak non-repetitive forward surge current of 100 amperes.
This model is designed for surface mounting, facilitating compact and automated PCB assembly.
The ES3DB-13-F has a single diode configuration with a 2-pin design.
It is suitable for use in power management, protection circuits, and high-frequency applications such as power supplies and switching regulators.
This diode is manufactured in China under strict quality controls.
It is a silicon junction switching diode, designed for efficient switching performance in electronic applications.
