DiodesZetex 4-Element Uni-Directional TVS Diode Array 6-Pin SOT-26 D1213A-04SO-7
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.3mm |
| Length | 3.1mm |
| Model | D1213A-04SO-7 |
| Width | 1.7mm |
| Mount Type | Surface |
| Series | D1213A |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-26 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 6 |
| Number of Elements per Chip | 4 |
| Clamping Voltage VC | 17V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Complex Array |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6V |
| Maximum Reverse Stand-off Voltage Vwm | 3.3V |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 5A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Features a complex diode array configuration for enhanced protection performance.
- Supports a minimum breakdown voltage of 6 volts and maximum operating temperature of 150°C.
- Offers a maximum peak pulse current of 5 amperes for transient event handling.
- Designed for surface mount applications with a compact SOT-26 package size.
- Includes electrostatic discharge (ESD) protection for semiconductor and electronic circuits.
- Operates over a temperature range from -65°C to 150°C ensuring high reliability.
- Complies with automotive standard AEC-Q101 for robust automotive use.
- Compact dimensions with length 3.1 mm, width 1.7 mm, and height 1.3 mm for space-saving PCB layout.
Product Description
DiodesZetex D1213A-04SO-7 is a 4-element uni-directional TVS diode array designed with a complex diode configuration to provide superior transient voltage suppression. Housed in a compact 6-pin SOT-26 surface mount package, this diode array is ideal for protecting sensitive electronic components against voltage surges and electrostatic discharge.
Operating with a minimum breakdown voltage of 6 V and a maximum reverse standoff voltage of 3.3 V, the device effectively clamps voltage spikes up to 17 V. It supports a peak pulse current of 5 A, enabling it to handle high transient power with reliability.
The device's operating temperature range from -65°C to 150°C and compliance with automotive standards (AEC-Q101) ensure its suitability for harsh and demanding environments including automotive, industrial, and commercial electronics applications.
The device offers ESD protection and features a low reverse leakage current of 1 µA, contributing to energy efficiency in sensitive circuits. Its small form factor with a length of 3.1 mm, width of 1.7 mm, and height of 1.3 mm makes it suitable for compact PCB designs where space is critical.
Complex diode array configuration enhances protection effectiveness. Compact SOT-26 surface mount package for space-saving PCB layout. High maximum peak pulse current of 5 amperes supports robust transient suppression. Wide operating temperature range from -65°C up to 150°C for reliable operation.
Automotive-grade quality compliant with AEC-Q101 standards. Low reverse leakage current reduces power loss and improves efficiency. Quad element design provides multi-line data protection capability.
This DiodesZetex TVS Diode Array is commonly used in industrial electronics, automotive electronics, telecommunications, and data line protection applications to safeguard circuits from damage caused by voltage surges and ESD events. It is a reliable component for enhancing device longevity and performance in transient-prone environments.
Browse EnvMart for more semiconductor protection devices and diode arrays to meet your electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum peak pulse current for this model is 5 amperes, allowing it to handle high transient power effectively.
This diode array has a minimum breakdown voltage of 6 volts, which is essential for its transient voltage suppression capabilities.
The dimensions of the SOT-26 package are 3.1 mm in length, 1.7 mm in width, and 1.3 mm in height, making it suitable for compact PCB layouts.
The operating temperature range for this model is from -65°C to 150°C, ensuring reliable performance in various environments.
Yes, this model includes electrostatic discharge (ESD) protection, safeguarding sensitive electronic circuits from voltage surges.
The D1213A-04SO-7 complies with the automotive standard AEC-Q101, indicating its suitability for automotive applications.
The clamping voltage (VC) for this model is 17 volts, which helps to limit voltage spikes effectively.
This diode array has a maximum reverse leakage current of 1 µA, contributing to energy efficiency in sensitive circuits.
The D1213A-04SO-7 features a complex diode configuration with 4 elements per chip, enhancing its protection capabilities.
This TVS diode array is designed for surface mounting, making it suitable for various PCB applications.
The maximum reverse stand-off voltage (Vwm) for this model is 3.3 volts, which is critical for its operation in protecting circuits.
This diode array is commonly used in industrial electronics, automotive electronics, telecommunications, and data line protection applications.
