TE Connectivity Trio-Mate 2.54 mm Pitch 5 Way Right Angle Female FPC Connector Solder 5-487508-4

TE Connectivity 5-487508-4 Trio-Mate 2.54 mm Pitch 5 Way Right Angle Female FPC Connector is a high-quality flexible film connector designed for robust and reliable PCB connections in industrial and electronic applications.

This connector supports flat flexible cables (FFC), flexible printed circuits (FPC), and membrane switch circuits ranging from 0.13 to 0.38 mm in thickness at the contact area, enabling versatile use in various electronics assembly tasks.

The connector features phosphor bronze contacts with tin over copper plating, providing excellent conductivity and corrosion resistance while maintaining durability during repeated use. The housing is made of black UL 94V-0 rated polyethylene terephthalate thermoplastic, ensuring flame retardancy and mechanical strength.

Designed for through-hole mounting with a right-angle orientation, this connector facilitates efficient PCB layout and assembly. Its Low Insertion Force (LIF) contact system eases cable installation and removal, supporting up to 25 reuse cycles with cables of the same thickness.

Operating temperature range of -55°C to 105°C makes this connector suitable for demanding industrial, laboratory, telecommunications, and manufacturing environments where thermal stability is critical.

The single-row, 5-contact design offers a 2.54 mm pitch that aligns with industry standards, making it compatible with a wide range of cable assemblies and FPC applications. Connector features 5 contacts for secure electrical connection.

Contact material is phosphor bronze ensuring durability. Designed for through-hole mounting with right angle orientation. Termination type is solder, suitable for PCB integration. Rated for operating temperatures from -55°C to 105°C.

Housing made of black UL 94V-0 thermoplastic polyethylene terephthalate. Contact plating utilizes tin over copper for corrosion resistance. Compatible with flat flexible cables (FFC) 0.13 to 0.38 mm thick. High extraction force connector reusable up to 25 times with same cable thickness.

Offers one row with Low Insertion Force (LIF) for easy assembly.

This TE Connectivity Trio-Mate connector is widely used in electronics manufacturing, product prototyping, telecommunications equipment, and industrial control systems where reliable flexible film cable connections are essential.
