TE Connectivity Trio-Mate 2.54 mm Pitch 7 Way Right Angle Female FPC Connector, Solder 5-487508-6
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V ac |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Polyethylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | Trio-Mate |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | FFC |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin over Copper |
| Number of Contacts | 7 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | LIF |
Key Features
- The connector supports a current rating of 1A and voltage rating of 250V ac.
- It features phosphor bronze contact material with tin over copper plating.
- The pitch between contacts is 2.54 mm enabling compatibility with standard flat flexible cables (FFC).
- Connector housing is made from black UL 94V-0 rated polyethylene terephthalate material for flame resistance.
- Operating temperature ranges from -55°C to 105°C ensuring performance in harsh environments.
- The connector’s right angle orientation is suitable for space-efficient PCB mounting.
- Insertion force follows LIF (Low Insertion Force) standards, facilitating easy cable insertion and removal.
- Designed for flexible film connectors accepting FFC or FPC cables from 0.13 to 0.38 mm thickness.
Product Description
TE Connectivity 5-487508-6 Trio-Mate 2.54 mm Pitch 7 Way Right Angle Female FPC Connector is engineered for reliable electrical connections suitable for industrial, electronic, and manufacturing applications.
This connector is designed to connect Flat Flexible Cable (FFC), flexible printed circuits (FPC), or membrane switch circuitry with cable thickness ranging from 0.13 to 0.38 mm in the contact area. It features phosphor bronze contact material with tin over copper plating to ensure low resistance and longevity.
The housing is constructed from black UL 94V-0 thermoplastic polyethylene terephthalate providing flame retardance and mechanical strength. Its right angle mounting style offers efficient use of PCB space while facilitating through hole solder termination.
The connector sustains operating temperatures from -55°C to 105°C, supporting a current rating of 1A and a voltage rating of 250V AC, qualifying it for a variety of electronic devices and control systems. A low insertion force (LIF) mechanism allows easy cable insertion and removal, enhancing maintenance and assembly efficiency.
The Trio-Mate family is known for their robustness, supporting up to 25 re-uses with the same cable thickness, making these connectors ideal for applications requiring frequent disconnection or replacement.
The connector supports a current rating of 1A and voltage rating of 250V AC. It features phosphor bronze contact material with tin over copper plating. Connector housing made of UL 94V-0 polyethylene terephthalate for high flame resistance.
Through hole mounting type with right angle orientation for PCB assembly. Accepts FFC/FPC cables from 0.13 to 0.38 mm thickness. Low insertion force (LIF) ensures ease of cable connection. Operating temperature range is -55°C to 105°C for wide environmental suitability.
Durable design reusable up to 25 times with consistent cable thickness.
Ideal for electronic component manufacturers, industrial automation, and equipment requiring robust electrical connections. Explore more TE Connectivity connectors and accessories for diverse application needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector supports a current rating of 1A and a voltage rating of 250V AC.
The pitch between contacts is 2.54 mm, enabling compatibility with standard flat flexible cables (FFC).
It features a through hole mounting type with a right angle orientation suitable for PCB assembly.
The operating temperature range is from -55°C to 105°C, making it suitable for harsh environments.
The housing is made from black UL 94V-0 rated polyethylene terephthalate, and the contacts are made of phosphor bronze with tin over copper plating.
This model has 7 contacts, all of which are female.
It follows the Low Insertion Force (LIF) standards, facilitating easy cable insertion and removal.
It is designed to accept flexible film connectors with cable thickness ranging from 0.13 to 0.38 mm.
This connector is designed to be reusable up to 25 times with the same cable thickness.
It uses a solder termination type, suitable for reliable electrical connections.
This connector is part of the Trio-Mate series by TE Connectivity.
The country of origin for this connector is India.
