Nisshinbo Micro Devices Operational Amplifier 1.3 MHz 15V 8-Pin SSOP NJM3414AV-TE1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nisshinbo Micro Devices |
| Height | 1.15mm |
| Length | 3.5mm |
| Model | NJM3414AV-TE1 |
| Width | 4.4mm |
| Mount Type | Surface |
| Series | NJM3414 |
| Output Current | 70mA |
| Maximum Operating Temperature | 75°C |
| Package Type | SSOP |
| Minimum Operating Temperature | -20°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 500 nA |
| Vos - Input Offset Voltage | 5 mV |
| Slew Rate | 1V/μs |
| Input Offset Current | 100 nA |
Key Features
- Surface mount type with SSOP package for compact PCB design.
- Operates within a voltage range of 5V to 15V, ideal for varied power requirements.
- Features low input bias current of 500 nA for precision amplification.
- Slew rate of 1 V/μs ensures responsive signal processing.
- Compact dimensions of 3.5mm length, 4.4mm width, and 1.15mm height minimize PCB space.
- Supports operating temperatures from -20°C to 75°C for enhanced reliability.
- Built to deliver output current up to 70mA for driving diverse loads.
- Includes low input offset current of 100 nA and input offset voltage of 5 mV for accuracy.
Product Description
Nisshinbo Micro Devices NJM3414AV-TE1 operational amplifier offers high performance for electronic amplification applications. This dual-channel device operates with a gain bandwidth product of 1.3 MHz and supports supply voltages from 5V to 15V, making it adaptable to various industrial and consumer electronics.
The component features a surface mount SSOP package with compact physical dimensions of 3.5 mm length, 4.4 mm width, and 1.15 mm height, facilitating efficient PCB layout and space savings. It is engineered for stable operation in temperatures ranging from -20°C up to 75°C, suitable for a wide range of environmental conditions.
Performance characteristics include a low input bias current of 500 nA and low input offset current of 100 nA, with an input offset voltage of 5 mV. The slew rate of 1 V/μs ensures rapid response to input signal changes, while a maximum output current of 70 mA supports driving of varying load requirements.
This operational amplifier does not carry specific automotive standards or certifications but is a reliable choice for general electronic circuits requiring precise signal management. It is part of the NJM3414 series by Nisshinbo Micro Devices, known for quality and consistency.
Surface mount type with SSOP package for compact PCB design. Dual channel configuration enhances signal processing capability. Gain bandwidth product of 1.3 MHz enables moderate frequency applications. Low input bias and offset currents minimize signal error.
Operational temperature range supports industrial use. Compact dimensions optimize PCB space utilization. Slew rate of 1 V/μs for effective signal handling. Max output current of 70 mA for versatile load driving. Part of the reliable NJM3414 operational amplifier series.
This operational amplifier is suitable for use in industrial, laboratory, manufacturing, and electronics design applications requiring precise dual-channel amplification. It is well suited for circuit boards demanding small form factors and consistent electrical performance.
Explore the Electronics & Electricals category on EnvMart for more semiconductor amplifiers and components, including a broad selection of Operational Amplifiers tailored to various industrial requirements.
