Nisshinbo Micro Devices 1-Channel Linear Voltage Regulator 1.5A 9V SOT-89-3 NJM7809DL1A-TE1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nisshinbo Micro Devices |
| Model | NJM7809DL1A-TE1 |
| Mount Type | Surface |
| Series | NJM7800 |
| Output Current | 1.5A |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-89-3 |
| Load Regulation | 180 mV |
| Minimum Operating Temperature | -40°C |
| Regulator Type | Linear Voltage |
| Number of outputs | 1 |
| Maximum Input Voltage | 35V |
| Output Voltage | 9V |
| Quiescent Current | 6mA |
| Line Regulation | 180 mV |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 4V |
| Pin Count | 3 |
Key Features
- Designed for precise voltage regulation in electronic circuits.
- Supports up to 1.5A output current for high-demand applications.
- Stable 9V linear voltage output enhances circuit performance.
- Features thermal overload and internal current limiting for reliability.
- Surface mount SOT-89-3 package for efficient PCB integration.
- Operates in wide temperature range from -40°C to 125°C.
- Complies with RoHS requirements for restricted substances.
- Used in power management, telecom, industrial, and consumer electronics.
Product Description
Nisshinbo Micro Devices NJM7809DL1A-TE1 is a high-performance 1-channel linear Voltage Regulator engineered for professional electronics applications. This device delivers a stable 9V output with up to 1.5A current, making it ideal for circuits that require reliable power management. The SOT-89-3 surface mount package ensures compatibility with modern PCB designs and automated assembly processes.
With precise regulation and low quiescent current (6mA), the NJM7809DL1A-TE1 supports demanding applications such as industrial controllers, telecom systems, consumer electronics, and instrumentation. The integrated internal protection circuitry, including thermal shutdown and current limiting, provides robust safety against component damage and environmental stress.
Designed for precise voltage regulation in electronic circuits. Supports up to 1.5A output current for high-demand applications. Stable 9V linear voltage output enhances circuit performance. Features thermal overload and internal current limiting for reliability.
Surface mount SOT-89-3 package for efficient PCB integration. Operates in wide temperature range from -40°C to 125°C. Complies with RoHS requirements for restricted substances. Used in power management, telecom, industrial, and consumer electronics.
The NJM7809DL1A-TE1 features a line and load regulation of 180 mV, ensuring consistent output even across varying input voltages. Designed for a minimum input voltage of 4V and a maximum of 35V, it fits a broad spectrum of DC supply configurations. Its three-terminal configuration simplifies circuit layout and maintenance.
Applications include equipment requiring high voltage stability, such as laboratory instruments, automation systems, embedded platforms, and any industrial solution relying on linear voltage regulation. Its RoHS compliance makes it suitable for environmentally conscious manufacturing.
Explore more voltage regulation and power management ICs from Nisshinbo Micro Devices in the EnvMart electronics regulator category for innovative circuit solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a stable output voltage of 9V.
It supports a maximum output current of 1.5A, suitable for high-demand applications.
This unit operates within a temperature range of -40°C to 125°C.
It requires a minimum input voltage of 4V and can handle a maximum of 35V.
It comes in a surface mount SOT-89-3 package, facilitating efficient PCB integration.
The device features line and load regulation of 180 mV, ensuring consistent output under varying conditions.
The quiescent current for the NJM7809DL1A-TE1 is 6mA.
It includes thermal shutdown and current limiting to protect against component damage.
It is used in power management, telecom, industrial, and consumer electronics applications.
Yes, it complies with RoHS requirements for restricted substances.
This model has a single output configuration.
It belongs to the NJM7800 series of linear voltage regulators.
