Nisshinbo Micro Devices 1-Channel Low Dropout Voltage Regulator 3.3V 300mA SOT-89-5 TO-252-5 NJW4107U3-33B-TE1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nisshinbo Micro Devices |
| Model | NJW4107U3-33B-TE1 |
| Mount Type | Surface |
| Series | NJW4107 |
| Output Current | 300mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-89-5 TO-252-5 |
| Load Regulation | 14.8 mV |
| Minimum Operating Temperature | -40°C |
| Regulator Type | Low Dropout Voltage |
| Number of outputs | 1 |
| Maximum Input Voltage | 40V |
| Output Voltage | 3.3V |
| Quiescent Current | 135μA |
| Line Regulation | 23.5 mV |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 4V |
| Pin Count | 5 |
Key Features
- This regulator offers low dropout voltage performance ideal for battery-powered devices.
- Operates over a wide temperature range from -40°C to 125°C ensuring reliability under harsh conditions.
- Features surface mount package type SOT-89-5 TO-252-5 with 5 pins for easy PCB integration.
- Provides fast transient response and stable output voltage during line and load fluctuations.
- Quiescent current is low at 135μA helping to save power in standby mode.
- Supports maximum input voltage up to 40V and minimum input voltage of 4V.
- Complies with RoHS standards ensuring environmental safety.
- Includes thermal shutdown circuit for enhanced protection.
Product Description
Nisshinbo Micro Devices NJW4107U3-33B-TE1 is a single-channel low dropout voltage regulator providing a fixed output voltage of 3.3V with a max output current of 300mA. Its low dropout feature ensures high efficiency and stable voltage supply even during fluctuations in load or line conditions, making it suitable for sensitive electronic components.
The device comes in a compact SOT-89-5 TO-252-5 surface mount package with 5 pins that facilitates easy integration into electronic circuits, especially in modern PCB designs. It operates efficiently with a quiescent current of 135μA, which is beneficial for battery-powered and low-power devices.
Operating temperature ranges from -40°C up to 125°C, which qualifies this regulator for applications in automotive environments and other industrial conditions subjected to temperature variations. Additionally, the thermal shutdown circuit provides an extra layer of safety by preventing damage during overheating events.
The maximum allowable input voltage is 40V with a minimum input voltage of 4V, making this regulator versatile for various power supply configurations. This product is RoHS compliant, highlighting its adherence to environmental considerations.
Low dropout voltage performance ensures efficient power regulation. Wide operating temperature range from -40°C to 125°C. Compact surface mount package SOT-89-5 TO-252-5 (5 pins). Fast transient response for stable output voltage.
Low quiescent current of 135μA for energy savings. Maximum input voltage rating of 40V and minimum input voltage of 4V. Thermal shutdown circuit for protection against overheating. RoHS compliant for environmentally safe use.
Suitable for automotive and industrial applications requiring reliable voltage regulation.
This voltage regulator is a reliable choice for designers and engineers working on automotive electronics, industrial control systems, instrumentation, and power management modules demanding stable 3.3V supply with low dropout characteristics.
Explore further Voltage Regulators and power management ICs on EnvMart for comprehensive industrial and electronics solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a fixed output voltage of 3.3V.
The maximum output current is 300mA.
It operates efficiently over a wide temperature range from -40°C to 125°C.
The maximum allowable input voltage is 40V.
The minimum input voltage is 4V.
It is available in a compact SOT-89-5 TO-252-5 surface mount package with 5 pins.
The quiescent current is low at 135μA, which helps save power in standby mode.
Yes, it includes a thermal shutdown circuit for enhanced protection against overheating.
The line regulation is 23.5 mV and the load regulation is 14.8 mV.
Yes, it complies with RoHS standards, ensuring environmental safety.
This voltage regulator is suitable for automotive electronics, industrial control systems, and power management modules requiring stable 3.3V supply.
It belongs to the NJW4107 series.
