Panasonic Film Capacitor 220 nF 50V DC 50V AC Surface Mount PPS ECHU1H224JX9

Panasonic ECHU1H224JX9 film capacitor is a high-performance PPS film capacitor designed for surface mount technology (SMT) assemblies. Featuring a capacitance of 220 nF and rated voltages of 50 V dc and 50 V ac, this component is engineered for precision electronic circuits requiring stability and reliability.

Constructed from stacked metallised PPS film, the capacitor employs a mould-less design that contributes to its compact size and lightweight characteristics. It provides a low equivalent series resistance (ESR), which improves performance in filtering and resonance applications.

The ECHU(X) series is rated for a maximum operating temperature of 125°C, making it suitable for demanding industrial and commercial electronics operating in harsh thermal environments. This capacitor is specifically designed for reflow soldering processes, allowing efficient automated placement and soldering on printed circuit boards (PCBs).

This capacitor is ideally used in time-constant applications, oscillation circuits, resonance filtering, and audio circuit designs where tight capacitance tolerances and stable electrical characteristics are required.

Constructed from stacked metallised PPS film offering mould-less design. Compact and lightweight design with low ESR. Rated for maximum operating temperature of 125°C. Reflow soldering compatible for SMT assembly. Applications include timing circuits, oscillators, resonance, filtering, and audio equipment.

RoHS compliant environmentally friendly product. Physical dimensions: 6 mm length, 4.1 mm width, 2.8 mm height. Manufactured in Japan for assured quality.

This Panasonic film capacitor ECHU1H224JX9 series is a reliable choice for electronic component assemblies in commercial, industrial, and electronic manufacturing sectors. Its high temperature rating and low ESR characteristics make it suitable for use in demanding applications where performance consistency is critical.
