Vishay TRANSZORB® 1-Element Uni-Directional TVS Diode 600 W, Surface Mount DO-214 Package SMBJ30A-E3/5B
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.24mm |
| Length | 4.57mm |
| Model | SMBJ30A-E3/5B |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 48.4V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 33.3V |
| Maximum Reverse Stand-off Voltage Vwm | 30V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 12.4A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Offers excellent clamping capability with a maximum clamping voltage of 48.4 V.
- Designed for surface mount applications with a compact DO-214 package.
- Operates reliably from -55°C to 150°C ambient temperature range.
- Features fast response time and low incremental surge resistance.
- Provides ESD protection complying with automotive standard AEC-Q101.
- Maximum peak pulse current rating is 12.4 A at 10x1000 µs waveform.
- Minimum breakdown voltage is 33.3 V ensuring robust transient suppression.
- Suitable for industrial, automotive, and electronic equipment transient overvoltage protection.
Product Description
Vishay SMBJ30A-E3/5B is a single-element uni-directional transient voltage suppressor (TVS) diode designed for reliable transient overvoltage protection in sensitive electronic and automotive circuits. It provides a peak pulse power dissipation of 600 W and is housed in a low profile DO-214 (SMBJ) surface mount package ideal for compact PCB layouts.
Operating within a temperature range of -55°C to 150°C, this device ensures excellent clamping performance, limiting voltage spikes to a maximum of 48.4 V under surge conditions. Its fast response time and low incremental surge resistance enable rapid and efficient suppression of transient voltage events, safeguarding downstream components.
The device is RoHS compliant and meets the stringent AEC-Q101 automotive standard, making it suitable for automotive electronics requiring rigorous reliability and quality. Its uni-directional diode configuration with a 2-pin connection simplifies integration into protection circuits.
With a minimum breakdown voltage of 33.3 V and a maximum reverse standoff voltage of 30 V, it offers effective protection against voltage transients while allowing normal operation under rated voltages. The maximum peak pulse current of 12.4 A supports protection against high surge currents typical in industrial, telecommunications, and automotive environments.
Excellent transient voltage suppression up to 600 W peak power. Compact DO-214 surface mount package for space-saving PCB design. Wide operating temperature range suitable for harsh environments. Fast response time minimizes circuit damage during voltage spikes.
Automotive-grade quality meeting AEC-Q101 standards. Uni-directional diode configuration with 2-pin mounting. Low leakage current of 1 μA maintains circuit integrity. Industrial and automotive transient voltage protection applications.
This Vishay TRANSZORB® TVS diode series is widely used in electronic equipment, power supplies, and communications systems to improve overall system robustness by efficiently diverting harmful voltage surges away from protected devices. It integrates easily into PCB layouts requiring reliable transient voltage suppression in demanding industrial or automotive environments.
Browse Vishay TRANSZORB® TVS Diode products at EnvMart for a comprehensive selection of transient voltage suppressors tailored to your industrial and automotive protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum peak pulse power dissipation of this TVS diode is 600 W.
The clamping voltage for this model is 48.4 V.
It operates reliably within a temperature range of -55°C to 150°C.
The minimum breakdown voltage is 33.3 V.
The maximum peak pulse current rating is 12.4 A at a 10x1000 µs waveform.
This diode is housed in a DO-214 surface mount package.
It has a 2-pin configuration.
It complies with the AEC-Q101 automotive standard.
This model is a uni-directional diode.
It is suitable for transient overvoltage protection in industrial, automotive, and electronic equipment.
