Vishay TRANSZORB 1-Element Uni-Directional TVS Diode SMC Package 1.5 kW, 54 V Maximum Reverse Stand-off SMCJ54A-E3/57T
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | SMCJ54A-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 87.1V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 60V |
| Maximum Reverse Stand-off Voltage Vwm | 54V |
| Peak Pulse Power Dissipation Pppm | 1.5kW |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 17.2A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Designed for surface-mount mounting style.
- Single element configuration for uni-directional transient voltage suppression.
- Clamping voltage rated at 87.1 V for effective electrical protection.
- Operational temperature range from -55°C to 150°C ensures reliability.
- Peak pulse current capability of 17.2 A to handle transient surges.
- Low maximum reverse leakage current of 1 μA minimizes power loss.
- Certified compliant with automotive standard AEC-Q101.
- Provides Electrostatic Discharge (ESD) protection for sensitive circuits.
Product Description
Vishay SMCJ54A-E3/57T TRANSZORB® 1-Element Uni-Directional TVS Diode is designed to protect sensitive electronic components against transient voltage spikes by providing reliable 1.5 kW peak pulse power dissipation. Housed in a surface-mount SMC package, this diode features a maximum reverse stand-off voltage of 54 V and a low clamping voltage of 87.1 V, ensuring effective voltage suppression to safeguard circuits.
Its single-element uni-directional configuration allows current flow in one direction only, making it ideal for protecting power lines and other uni-directional circuits used in industrial, automotive, and electronic device applications.
The diode operates reliably across a wide temperature range from -55°C up to 150°C, suitable for harsh environments. It also meets automotive quality standard AEC-Q101, asserting its quality for automotive electronics protection.
With a peak pulse current capability of 17.2 A and minimal leakage current of 1 μA, it efficiently handles voltage transients and minimizes unwanted power dissipation. Dimensions of 7.11 mm length, 6.22 mm width, and 2.42 mm height allow compact PCB layouts without sacrificing protection.
Common industrial applications include transient voltage suppression in power supplies, automotive systems, industrial controls, and communication equipment. The device provides robust Electrostatic Discharge (ESD) protection and is part of the TRANSZORB TVS diode series known for high reliability in transient suppression.
Set to enhance electronic circuit safety, this component is an essential selection for engineers aiming at long system reliability and protection against voltage spikes. Designed for surface mounting with a compact SMC package.
Uni-directional single element diode providing precise voltage clamping. High transient power dissipation rated at 1.5 kW peak pulse power. Wide operating temperature range suitable for automotive and industrial environments.
Certified under AEC-Q101 automotive standards for quality assurance. Explore more components in the TVS Diode category at EnvMart for your transient voltage protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum reverse stand-off voltage of this model is 54 V.
This diode has a peak pulse power dissipation rating of 1.5 kW.
The clamping voltage is rated at 87.1 V, providing effective voltage suppression.
It can handle a peak pulse current of 17.2 A, making it suitable for transient surges.
The operational temperature range is from -55°C to 150°C, which ensures reliability in harsh environments.
This model is designed for surface-mount installation.
It features a single element configuration for uni-directional transient voltage suppression.
The dimensions are 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
It is certified compliant with the automotive standard AEC-Q101.
The maximum reverse leakage current is 1 μA, which helps minimize power loss.
Common applications include transient voltage suppression in power supplies, automotive systems, and industrial controls.
This model has a uni-directional configuration, allowing current flow in one direction only.
