Molex Micro-Lock Plus Female Connector Housing 1.25 mm Pitch 2 Way 1 Row Straight 505565-0201
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Molex |
| Orientation | Straight |
| Length | 4.5mm |
| Width | 6.1mm |
| Mount Type | Surface |
| Housing Material | Polyester |
| Series | Micro-Lock Plus |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| For Use With | 505431 Micro-Lock PLUS Terminal |
| Number of Contacts | 2 |
| Connector Gender | Female |
Key Features
- The connector housing features a 1.25 mm pitch with 2 ways and a single straight row.
- Constructed from durable polyester material suitable for surface mount applications.
- Offers electrical and mechanical reliability meeting stringent industry requirements.
- Compatible with 505431 Micro-Lock PLUS terminals for seamless integration.
- Ideal for automotive, industrial automation, and consumer electronics uses.
- Designed with positive locking mechanism to secure connections firmly.
- Originates from Japan ensuring high manufacturing standards.
- Provides color-coded options to aid assembly and reduce errors.
Product Description
The Molex 505565-0201 Micro-Lock Plus Female Connector Housing is a compact and reliable connector designed for use in various industrial and automotive applications. Featuring a 1.25 mm pitch and a two-way, single-row straight layout, this connector housing supports a robust electrical connection while maintaining a small footprint ideal for modern electronics.
Manufactured with high-quality polyester material, the housing is suited for surface mount applications, providing both mechanical durability and thermal resistance. The Micro-Lock Plus series is known for its positive locking mechanism, which ensures the stability of the connection even under challenging environmental conditions.
This connector housing is compatible with the 505431 Micro-Lock PLUS terminal, enabling straightforward assembly and secure mating. Its design also incorporates color-coded options to facilitate accurate and efficient wiring in manufacturing settings.
Typical applications include automotive steering wheel and paddle shift assemblies, combination switches, various lighting solutions such as head, rear, and side-mirror lights, as well as industrial automation equipment and consumer electronics including gaming machines, drones, air conditioners, and vacuum cleaners.
The Connector Housing features a 1.25 mm pitch with 2 ways and a straight single row configuration. Durable polyester housing material ensures longevity and reliability. Positive lock design provides secure and stable electrical connections.
Compatible with 505431 Micro-Lock PLUS terminals for easy installation. Color coded for ease of assembly in manufacturing environments. Widely used in automotive, industrial, and consumer electronic applications. Manufactured in Japan under high quality standards.
Explore the comprehensive range of Molex connectors and housings on EnvMart for your electronics and industrial connectivity needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of the Molex Micro-Lock Plus Female Connector Housing is 1.25 mm.
This connector housing features 2 ways in a single row configuration.
It is constructed from durable polyester material suitable for surface mount applications.
The length of the housing is 4.5 mm and the width is 6.1 mm.
This housing is compatible with the 505431 Micro-Lock PLUS terminals.
It is widely used in automotive, industrial automation, and consumer electronics applications.
It is designed with a positive locking mechanism to secure connections firmly.
The orientation of this connector housing is straight.
This connector housing has 2 contacts.
It originates from Japan, ensuring high manufacturing standards.
This connector housing uses a surface mount type.
This connector housing belongs to the Micro-Lock Plus series.
