DiodesZetex 5.6 V Common Cathode Zener Diode 300 mW 5% Tolerance Surface Mount 3-Pin SOT-23 DZ23C5V6-7-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 5.6 V Common Cathode Zener Diode 300 mW 5% Tolerance Surface Mount 3-Pin SOT-23 DZ23C5V6-7-F

Name: DiodesZetex 5.6 V Common Cathode Zener Diode 300 mW 5% Tolerance Surface Mount 3-Pin SOT-23 DZ23C5V6-7-F
Brand: DiodesZetex
SKU: 217442
Price: 0.07 USD
Availability: InStock



Category Zener Diode Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.1mm
Length	3mm
Model	DZ23C5V6-7-F
Mount Type	Surface
Series	DZ23C5V6
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	2
Maximum Power Dissipation Pd	300mW
Diode Configuration	Common Cathode
Test Current It	5mA
Maximum Reverse Leakage Current	100nA
Nominal Zener Voltage Vz	5.6V
Zener Type	Voltage Regulator
Maximum Zener Impedance	400Ω

Key Features

This diode provides a voltage tolerance of ±5% ensuring precise voltage regulation.
The device supports a maximum operating temperature up to 150°C and minimum down to -65°C.
It features a maximum reverse leakage current of 100 nA and maximum zener impedance of 400 Ω.
Designed for surface mount applications, it utilizes a compact SOT-23 package with dimensions 3 mm length and 1.1 mm height.
The diode incorporates two elements per chip and supports a test current of 5 mA for verification.
It is suitable for industrial and electronic circuit voltage regulation and protection applications.

Product Description

DiodesZetex DZ23C5V6-7-F is a 5.6 V nominal Zener diode with a common cathode configuration, designed for surface mount technology in a compact SOT-23 3-pin package. Rated for a maximum power dissipation of 300 mW, this device ensures robust voltage regulation within electronic systems.

The diode offers a tight voltage tolerance of ±5%, contributing to accurate voltage stabilization in power and signal conditioning circuits. It operates reliably over a wide temperature range from -65°C to 150°C, making it suitable for various industrial, laboratory, and manufacturing applications.

Electrical characteristics include a maximum reverse leakage current of 100 nA and a maximum zener impedance of 400 Ω, which optimize performance and reduce power losses. The diode supports a test current of 5 mA, facilitating quality control and performance verification.

The small footprint of the SOT-23 package (3 mm length, 1.1 mm height) enables high-density PCB designs and automated assembly processes. With two elements per chip, it is engineered for enhanced functionality and reliability.

This Zener diode is ideal for use in electronic component assemblies requiring precise voltage regulation, such as in power supplies, signal conditioning, and transient voltage suppression. Its surface mount form factor supports modern automated manufacturing practices.

This diode provides a voltage tolerance of ±5% ensuring precise voltage regulation. The device supports a maximum operating temperature up to 150°C and minimum down to -65°C. It features a maximum reverse leakage current of 100 nA and maximum zener impedance of 400 Ω.

Designed for surface mount applications, it utilizes a compact SOT-23 package with dimensions 3 mm length and 1.1 mm height. The diode incorporates two elements per chip and supports a test current of 5 mA for verification.

It is suitable for industrial and electronic circuit voltage regulation and protection applications. Explore our extensive range of Zener Diodes and semiconductor components at EnvMart for reliable and efficient electronics solutions.
