Preci-Dip DIL Socket 32 Contacts 2.54 mm Pitch Vertical Surface Turned Pin Open Frame 1A 110-87-632-41-105101

Preci-Dip 110-87-632-41-105101 DIL Socket is a high-quality 32 contact dual-in-line socket with 2.54 mm pitch designed for vertical surface mounting. It features an open frame construction with turned pins that provide reliable electrical contacts ideal for integrated circuit applications in electronic assemblies.

This socket supports a current rating of 1 ampere and can handle voltages up to 150 volts AC, making it suitable for various industrial electronic and power connector applications. The contacts are made of brass and beryllium copper alloy, plated with a gold and tin finish, ensuring excellent conductivity and resistance against corrosion.

The housing is constructed from rugged fiberglass reinforced polyethylene terephthalate material, providing mechanical resilience and durability in harsh environments. It is engineered for solder termination, optimized for reflow soldering methods including vapor phase processes. The Gull Wing terminations facilitate robust PCB connectivity and allow for hassle-free in-circuit testing.

This product operates reliably within a temperature range from -55 degrees Celsius to 125 degrees Celsius, suitable for demanding industrial, manufacturing, and laboratory environments that require consistent and durable connector solutions.

The precise dimensions include a pitch of 2.54 mm, a row width of 15.24 mm, length of 40.6 mm, width of 17.7 mm, and a depth of 2.8 mm. It is manufactured in Switzerland, adhering to quality and reliability standards. The socket also meets UL 94V_0 flame retardant criteria, enhancing its safety for use in electronics manufacturing.

This DIL socket is ideal for industrial electronics, laboratory equipment, manufacturing automation, and power connectors where secure IC mounting is essential. The open frame design allows for easy inspection and cleaning, improving maintenance efficiency in electronic assemblies.

Robust build quality ensures long operational life and dependable performance in harsh conditions. Preci-Dip 110 Series products provide standardized dimensions compatible with a wide range of IC packages and sockets. Available stock numbers include variants with and without center bars for different mounting and connection requirements.
